LEGRAND DA-LITE - Optional Screen Controller Connection

6
OPTIONAL SCREEN CONTROLLER CONNECTION:
Optional Screen
Controller Connector
120VAC 60Hz
230VAC 50Hz
Figure 4
1. Remove the cover plate labeled "Low voltage
connections" and the center cover plate.
2. Route the ethernet cable through the round platic
bushing and plug into the onboard RJ-45 port. Refer
to diagram 4.
Optional Screen
Controller Connector
