Leica TELEVID 77 - Technical Data for Televid Eyepieces

37
Technical Data – Eyepieces B 20x WW B 32x WW B 40x B 20 - 60x
System 6 lens elements 7 lens elements 6 lens elements 8 lens elements
Magnification 20x 32x 40x 20 - 60x
Exit pupil (EP 77) 3,85mm 2,41mm 1,93mm 3,85 -1,28mm
Field of vision 3,45°/60m 2,30°/40m 1,25°/22m 2,0° to 1,2°/34-20m
Length (with eye-cups pushed in) 68mm 70 mm 46mm 80mm
Diameter 53mm 54mm 45mm 53mm
Weight 246g 285g 102g 280g
Order no. 41009 41011 41003 41012
Deutsch
English
Technische Daten – Okulare B 20x WW B 32x WW B 40x B 20 - 60x
Aufbau 6 Linsen 7 Linsen 6 Linsen 8 Linsen
Vergrößerung 20x 32x 40x 20 - 60x
Austrittspupille (EP 77) 3,85mm 2,41mm 1,93mm 3,85 bis 1,28mm
Sehfeld 3,45°/60m 2,30°/40m 1,25°/22m 2,0° bis 1,2°/34 -20m
Länge (bei eing. Augenm.) 68mm 70mm 46mm 80mm
Durchmesser 53mm 54mm 45mm 53mm
Gewicht 246g 285g 102g 280g
Bestell-Nr. 41009 41011 41003 41012
