NET Series
Software Operation
Page 100 Firmware Ver. 1.00.42/Software Ver. 1.0.2.6 LEIGHTRONIX, INC.
2010-07-09
Table 18, Editable DVply-Controlled Device Event Fields
FIELD DESCRIPTION
Lock Box At the top is a checkbox for locking or unlocking the event. A locked
event’s time is fixed and can be edited. Checking this box causes the
“Time” field below to become enabled.
Name Allows a name up to 31 characters to be typed.
Device Allows a different device of the same format to be chosen. Its
associated input will appear in the Input field.
Comment Allows up to 31 characters to be typed. If the event is locked, the
event “Time” can be modified. This is the scheduled “On-Air“ time of
the event.
Start
Command
Choose from the following commands: “Play,” “Stop,” “Cue/Play,”
“Pause,” and “Record.” It will almost always be “Cue/Play.”
Title:Chapter is the program location on the disc. Setup is fixed in the
device properties.
Preroll Enter as needed.
Reset time Reset time is unused.
Length Enter duration of the event.
Event End
Command
Choose from the following commands: “Play,” “Stop,” “Cue/Play,”
“Pause,” and “Record.” It will usually be “Stop.”
Fallback
input field
If desired, enter the input to be taken to the output at the end of the
event.
