Technical Data
LHS SYSTEM 20S 20L 40S 40L 60S 60L
Voltage V~ 100 – 230 200 – 230 100 – 230 3×230 – 3×440 3×230 – 3×480 3×230 – 3×480
Frequency Hz 50/60 50/60 50/60 50/60 50/60 50/60
Power
consumption kW 1.0 / 2.0 3.3 2.0 / 4.0 2.0 / 4.0 4.0 / 6.0 5.0 –16.0
Air flow l/min. min. 100 min. 200 min. 200 min. 200 min. 300 min. 400
Temperature °C max. 650 max. 650 max. 650 max. 650 max. 650 max. 650
Ambient °C
temperature <65 <65 <65 <65 <65 <65
Weight kg 0.55 0.65 0.85 0.95 3.15 3.65
Size mm 237×97×92 267×97×92 246×112×103 276×112×103 379×116×137 379×116×137
Mark of conformity ¬¬¬¬¬¬
Marl of approval ††††††
Certification scheme CCA CCA CCA CCA CCA CCA
Protection class I ‡‡
Protection class II ¶¶¶ ¶
2
Danger! When opening up the tool, live components and
connections are exposed. The mains plug must be removed
from the main socket before opening up the tool. Caution
separate source voltage.
Incorrect installation and use of air heaters can present
a fire and explosion hazard, particularly in the proximity of
flammable materials and explosive gases.
Do not touch the element housing and nozzle when hot
as they can cause burns. Do not point the hot air flow at
people or animals.
WARNING
The tool must be operated with supervision. Warmth can
reach combustible materials, which are out of sight.
The voltage rating stated on the tool should correspond
to the mains voltage.
IEC/EN 61000-3-11; Z
max
= 0.047
Ω
+ j 0.029
Ω
. If necessary,
consultate supply authority.
Protect the tool from dampness and wet.
100
480
CAUTION
The tool with protection class I should be earthed using a
protective conductor.
