LEM Poseidon 218

To Next Page

To Previous Page

1313

141018 ** 20 Contacts Vert Female Connector

141015 ** 14 Contacts Vert Female Connector

141012 ** 8 Contacts Vert Female Connector

141011 ** 6 Contacts Vert Female Connector

141010 ** 4 Contacts Vert Female Connector

140958 ** 26 Contacts Vert Female Board Connector Din41651

140935 ** 6 Contacts Hor Male Connector

140890 ** 4 Contacts Hor Male Single-Strip

103017 ** 74HC4051DW SOIC 8ch Analog Multiplexer

054036 ** 1K 1/10w 5% Smd Resistor 0805

054024 ** 100E 1/10w 5% Smd Resistor 0805

050491 ** 10K 1/4W 5% Resistor

050451 ** 4K7 1/4W 5% Resistor

011060 ** 100n 50V 10% Cer. Cap. Smd CL2 Y5V 0805

768263768263

768263

DX Board (Pcb#313089)DX Board (Pcb#313089)

DX Board (Pcb#313089)

NOTE:NOTE:

NOTE:

/0/0

suffix specify with PEGASUS-212 O.S. loaded in FLASH memory.suffix specify with PEGASUS-212 O.S. loaded in FLASH memory.

suffix specify with PEGASUS-212 O.S. loaded in FLASH memory.

/1/1

suffix specify with PEGASUS-118 O.S. loaded in FLASH memory.suffix specify with PEGASUS-118 O.S. loaded in FLASH memory.

suffix specify with PEGASUS-118 O.S. loaded in FLASH memory.

/2/2

suffix specify with POSEIDON-212 O.S. loaded in FLASH memory.suffix specify with POSEIDON-212 O.S. loaded in FLASH memory.

suffix specify with POSEIDON-212 O.S. loaded in FLASH memory.

/3/3

suffix specify with POSEIDON-218 O.S. loaded in FLASH memory.suffix specify with POSEIDON-218 O.S. loaded in FLASH memory.

suffix specify with POSEIDON-218 O.S. loaded in FLASH memory.

768264768264

768264

****

AD/DA Converter Board (Pcb#313111)AD/DA Converter Board (Pcb#313111)

AD/DA Converter Board (Pcb#313111)

106001 *** MC33078P SOIC Dual Low Noise Op. Amp.

103064 *** AK5383VS Dual DeltaSigma 96KHz 24bit ADC

103063 *** AK4393VF Dual MultiBit 96KHz 24bit DAC

055048 *** 10K 1/16w 5% Smd Resistor 0603

055044 *** 4K7 1/16w 5% Smd Resistor 0603

055042 *** 3K3 1/16w 5% Smd Resistor 0603

055040 *** 2K2 1/16w 5% Smd Resistor 0603

055016 *** 22E 1/16w 5% Smd Resistor 0603

031007 *** 10u 16V 20% Smd Electrolytic Tantalium Capacitor

030485 *** 100u 25V 20% Vert Electrolytic Capacitor

011260 *** 100n 16V 10% Cer. Cap. Smd CL2 X7R 0603

011248 *** 10n 16V 10% Cer. Cap. Smd CL2 X7R 0603

011240 *** 2n2 16V 10% Cer. Cap. Smd CL2 X7R 0603

011234 *** 680p 16V 10% Cer. Cap. Smd CL2 X7R 0603

250524 ** 25x25mm Thermoconductor Adhesive

231000 ** BLM21A102STP Smd EMI Coil For Signal

210215 ** Adhesive Rubber Foam 10x1.9mm (Specify mt)

177690 ** Heatsink

171039 ** Ground Leaf

142001 ** 32Pin PLCC SMD Socket

141018 ** 20 Contacts Vert Female Connector

141015 ** 14 Contacts Vert Female Connector

141012 ** 8 Contacts Vert Female Connector

141011 ** 6 Contacts Vert Female Connector

140935 ** 6 Contacts Hor Male Connector

140924 ** 22 Contacts P=1.27mm Male Strip

120276 ** B2.9x6.5mm Screw

106003 ** MAX709 Power Monitor With Reset

105008 ** RED208 Risc Cpu and Dsp

104067 ** K9F6408UOA 64Mbitx8 Nand Flash-mem.

104052 ** AT24C64 64Kbit Serial Access EEProm

104003 ** HM514260JP SOJ 4Mbit Dynamic Ram Ta=70ns

103000 ** 74HC14D Soic Hex Inverter Schmitt Trigger

081000 ** PMLL4148 Smd 100mA 75V Signal Diode

055103 ** 470E X4 1/16w 5% Smd Resistor Array

055101 ** 4K7 X4 1/16w 5% Smd Resistor Array

055100 ** 100E X4 1/16w 5% Smd Resistor Array

055072 ** 1M 1/16w 5% Smd Resistor 0603

055048 ** 10K 1/16w 5% Smd Resistor 0603

055044 ** 4K7 1/16w 5% Smd Resistor 0603

055039 ** 1K8 1/16w 5% Smd Resistor 0603

055038 ** 1K5 1/16w 5% Smd Resistor 0603

055035 ** 820E 1/16w 5% Smd Resistor 0603

055033 ** 560E 1/16w 5% Smd Resistor 0603

055030 ** 330E 1/16w 5% Smd Resistor 0603

055028 ** 220E 1/16w 5% Smd Resistor 0603

055024 ** 100E 1/16w 5% Smd Resistor 0603

042605 ** 10K0 1/4W 1% Metalized Film Resistor

031007 ** 10u 16V 20% Smd Electrolytic Tantalium Capacitor

030715 ** 1000u 6v3 20% Vert Electrolytic Capacitor

030485 ** 100u 25V 20% Vert Electrolytic Capacitor

011260 ** 100n 16V 10% Cer. Cap. Smd CL2 X7R 0603

011216 ** 22p 16V 10% Cer. Cap. Smd CL2 X7R 0603

011214 ** 15p 16V 10% Cer. Cap. Smd CL2 X7R 0603

011103 ** 1u 16V 10% Cer. Cap. Smd CL2 XTR 1206

010742 ** 12,288MHz Quartz

727636727636

727636

Controls Panel AssemblyControls Panel Assembly

Controls Panel Assembly

840838 ** 20 Wires 15cm Flat Cable

840826 ** 14 Wires 15cm Flat Cable

778166 ** Mains Cables Assembly

768266768266

768266

****

Input & Controls Board (Pcb#313104)Input & Controls Board (Pcb#313104)

Input & Controls Board (Pcb#313104)

230569 *** FL5R200PNT EMI Coil For Signal

141187 *** Hor Female XLR Socket (NC3FAH Neutrik)

141186 *** Hor Male XLR Socket (NC3MAH Neutrik)

141011 *** 6 Contacts Vert Female Connector

141010 *** 4 Contacts Vert Female Connector

140935 *** 6 Contacts Hor Male Connector

140911 *** 9 Contacts Hor Male Connector Din41652

110267 *** 1sw 2pos Horizontal Slider Switch

100919 *** MC33078 Dual LN Operational Amplifier

100750 *** MAX485ECPA RS-485/422 Transceiver

100734 *** MAX202E RS232 Drivers/Receiver

080272 *** 12V 1W 5% Zener Diode

080261 *** 10V 1W 5% Zener Diode

080243 *** 6V8 1W 5% Zener Diode

052048 *** 10K 1/8w 5% Resistor

050251 *** 100E 1/4W 5% Resistor

050131 *** 10E 1/4W 5% Resistor

042625 *** 15K0 1/4W 1% Metalized Film Resistor

042605 *** 10K0 1/4W 1% Metalized Film Resistor

042513 *** 1K82 1/4W 1% Metalized Film Resistor

042260 *** 0E 1/4W Resistor

030403 *** 47u 25V 20% Vert Electrolytic Capacitor

021012 *** 10n 63V 10% MKT Polyester Capacitor

010595 *** 100n 50V -20+80% Ceramic Cap. Multilayer

010271 *** 22p 50V 10% CL2 Ceramic Capacitor

768265768265

768265

****

Display Board (Pcb#313103)Display Board (Pcb#313103)

Display Board (Pcb#313103)

340856 *** 6,4mm Led Spacer

141018 *** 20 Contacts Vert Female Connector

141015 *** 14 Contacts Vert Female Connector

140529 *** Microswitch 12V 50mA 0.25mm

090194 *** BC560C TO92 LN Pnp Transistor

080752 *** 3mm Wide Diffused Red Led

080742 *** 3mm Wide Diffused Red-Grn Led

080717 *** HDN1105 7 Segments Display

052048 *** 10K 1/8w 5% Resistor

052044 *** 4K7 1/8w 5% Resistor

030246 *** 10u 25V 20% Low Prof Vert Electrolytic Capacitor

010595 *** 100n 50V -20+80% Ceramic Cap. Multilayer

667747 ** Controls Panel

347394 ** Rubber Switch Actuator

150591 ** 2 Digit Red Display Screen

141207 ** Mains Power Grey Socket (NTPW3MPB Neutrik)

141204 ** Mains Power Blue Socket (NTPW3MPA Neutrik)

120967 ** 5mm Spacer Screw

120584 ** M4 Black Nut

120582 ** M3 Black Nut

120482 ** 4mm Black Shakeproof Washer

120481 ** 3mm Black Shakeproof Washer

120451 ** 3.2x7x0.5 Black Washer

120256 ** B2.9x9.5tsp Black Screw

120030 ** M3x12tsp Black Screw

120029 ** M3x6tc Black Screw

110291 ** 16A 250Vac Bipolar Power Switch

727635727635

727635

Power Amplifier AssemblyPower Amplifier Assembly

Power Amplifier Assembly

SKK768163SKK768163

SKK768163

Amplifier Board (Pcb# PCB928)Amplifier Board (Pcb# PCB928)

Amplifier Board (Pcb# PCB928)

SKK091102 ** BCX41 SOT23 Smd Npn Transistor (EK)

SKK091101 ** BF623 SOT89 Smd Pnp Transistor (DB)

SKK091100 ** BF622 SOT89 Smd Npn Transistor (DA)

SKK081250 ** 13V 1/4W 5% SOT23 Smd Zener Diode

SKK081051 ** BYG70J 1A 600V SOD106 Smd Fast Recovery Diode

SKK081050 ** BAV103 0.25A 200V SOD80 Smd Fast Recovery Diode

SKK053146 ** 680E 1w 5% Smd Resistor 1218

SKK053111 ** 0E82 1w 5% Smd Resistor 1218

091001 ** BC857B/C TO236 Smd Pnp Transistor (9BB/C-3F/G)

091000 ** BC847B/C TO236 Smd Npn Transistor (8BB/C-1F/G)

SKK768162SKK768162

SKK768162

Supply Board (Pcb# PCB930)Supply Board (Pcb# PCB930)

Supply Board (Pcb# PCB930)

SKK080650 ** KBU1004 10A 400V Rectifier Diodes Bridge

SKK030892 ** 10000u 100V 20% Snap-In Electrolytic Capacitor

100059 ** 7805 +5V 1A Voltage Regulator

100058 ** 7905 -5V 1A Voltage Regulator

030805 ** 2200u 25V 20% Vert Electrolytic Capacitor

SKK110358SKK110358

SKK110358

60X25 24Vdc Fan60X25 24Vdc Fan

60X25 24Vdc Fan

SKK090007SKK090007

SKK090007

IRFP9240 TO3P P Mosfet TransistorIRFP9240 TO3P P Mosfet Transistor

IRFP9240 TO3P P Mosfet Transistor

SKK090006SKK090006

SKK090006

IRFP240 TO3P N Mosfet TransistorIRFP240 TO3P N Mosfet Transistor

IRFP240 TO3P N Mosfet Transistor

SKK080800 * NTC type Philips 2322-640-73473

340154 * TO3P/TO218 Mica Washer

340079 * TO220 Mica Washer

090183 * BC550C TO92 LN Npn Transistor

667750 * Left Amplifier Side

667749 * Right Amplifier Side

667748 * Amplifier Chassis

238092238092

238092

Transformer 900W 230Vac (EU)Transformer 900W 230Vac (EU)

Transformer 900W 230Vac (EU)

238093238093

238093

Transformer 900W 115Vac (US)Transformer 900W 115Vac (US)

Transformer 900W 115Vac (US)

180811 * Presets Adhesive Label (Pegasus118)

180810 * Presets Adhesive Label (Pegasus212)

180814 * Presets Adhesive Label (Poseidon212)

180815 * Presets Adhesive Label (Poseidon218)

180809 * Wiring Adhesive Label (Pegasus118)

180807 * Wiring Adhesive Label (Peg./Pos.212)

180813 * Wiring Adhesive Label (Poseidon218)

177777 * Internal Crossbar

150314 * 6.3mm Faston Insulator

150298 * 100x2.5mm Nylon Cable Tie

120841 * 6.3mm Female Brassed Faston

120832 * 18.8mm Hexagonal Spacer

120587 * M6 Black Nut

120582 * M3 Black Nut

120484 * 6mm Black Shakeproof Washer

120482 * 4mm Black Shakeproof Washer

120481 * 3mm Black Shakeproof Washer

120472 * 6.4x24x2 Black Washer

120131 * M6x80te Black Screw

120117 * M4x8tc Black Screw

120029 * M3x6tc Black Screw

120003 * M3x8tc Black Screw

020491 * 100nF 10% 250Vac Polyester Capacitor

Note:Note:

Note:

- All dimensions are in mm unless otherwise specified.

- The screw description is defined as follows:

type of screw + diameter + X + length + type of head

where type of screw is one of these:

M = Metric thread

B = Self-tapping screw for metal

WL = Self-tapping screw for wood

and type of head is one of these:

tc = cylinder Phillips head

ts = flared Phillips head

tt = rounded Phillips head

te = hexagonal nut head

tsp = flat flared Phillips head

tce = cylinder Allen hexagonal head

tspe = flat flared Allen hexagonal head

- The washer description is defined as follow:

hole diameter + X + external diameter + X + thick

- Each spare part is single quantity unless otherwise specified.

- Asterisk prefix explanation:

Omitted = First level spare part.

One asterisk = Second level, part of previous listed first level part.

Two asterisk = Third level, part of previous listed second level part.

Three asterisk = ............

- Any request for not above mentioned part must encompass specific description including:

1) Model name,

2) Section name,

3) Module code,

4) Reference name,

5) Quantity number.

LEM Poseidon 218 - Page 13
