5
MONO input channel
LO CUT
HI-PASS filter: allows to reduce the frequencies below 75 Hz with a 18 dB / Oct. slope. Thanks to this
filter it’s possible to eliminate unwanted subsonic frequencies, like, for examples the microphones rumble
due to the stage resonance.
LOW
LOW frequency control: gives 15dB boost or cut at 80Hz with a “SHELVING” curve.
MON
Control for the MONITOR send level.
The MON send is PRE-FADER: this means than the signal sent to the MON output is taken before the
control of the channel FADER, allowing a completely independent mix for the monitoring respect to the
main mix.
AUX 1&2
Control for the AUX sends level.
The AUX 1&2 sends are POST-FADER: this means than the signal sent to the AUX output is taken after
the control of the channel FADER and therefore its level is effected by the fader’s setting. For this reason,
the AUX send is suitable for the use with an external effect.
By means of an internal setting the AUX 1 can be switched PRE-FADER, allowing a second monitor
send to be used.
PAN
Centre-dented pot for controlling the signal’s pan: regulates stereo “position” of the signal with respect
to the main MIX L&R outputs. If PAN is turned completely to the LEFT, the signal will only be sent to
MIX LEFT, if it’s turned completely to the RIGHT, the signal will only be sent to MIX RIGHT. At intermediate
settings, the signal is sent to both MIX LEFT and RIGHT, but in different proportions.
MUTE / MIX B
Button for MUTE function.
When pressed, this switch mutes the channel signal to the L&R MIX outputs and, simultaneously, it assigns
the channel to the MIX B outputs.
SOLO
Button for SOLO function.
Allows the channel signal to be selected for the listening thru the CR and HEADPHONES outputs and
the visualization on the LED BARGRAPHS. According to the position of the SOLO MODE switch, the
listening and the visualization can be PRE- or POST-FADER.
LEVEL
Pot for controlling channel level: regulates the level of each channel sent to the MIX L&R (or MIX B)
outputs.
