Contact Numbering
Contact Numbering Example
Contacts are numbered counterclockwise on the
male insert and clockwise in the female insert, as
viewed from the termination side. Contact number
1 is marked with a half circle.
3
4
4
3 2
1
Female Insert
1
2
Male Insert
