e Pilot II assembly consists of a console, a magnet, and a
transmitter. A sensor in the transmitter counts the number
of times a magnet mounted in the right crank passes the sen-
sor.
e transmitter will then send a coded ANT+ signal to the
console containing the measured values.
e console has inboard receivers that pick up RPM signals
from the transmitter and heart rate signals from a telemetry
chest strap. e heart rate is then shown in the display win-
dow. e console will track cadence (RPMs), speed (MPH/
KPH), time, distance, and caloric expenditure.
NOTE:
Excessive use of the back light [ •
]will drain the
console batteries prematurely.
Expected life of the console batteries is 6 months to •
1 year.
If the console battery power is low, then “• BATT
LOW” will be shown in the display window for 2
seconds aer the display is turned on to inform
you to change the console batteries.
Expected life of the transmitter batteries is 6 •
months to 1 year.
DESCRIPTION
