SPECIFICATION
GENERAL
Supply Voltage DC 12V. Negative Ground
Current Consumption Max.10A
Power Output 25Watts X 4 (Measured at DC 14.4
V)
Number of channels 2 STEREO channels.
Unit Dimensions 178[W] X 101.5[D] X 50[H] mm.
FM SECTION
Frequency range 87.5MHz - 108MHz
Effective sensitivity 3uV.
I.F Frequency 10.7MHz.
AM SECTION
Frequency range 522KHz - 1620KHz
Effective sensitivity 40dB.
I.F Frequency 450KHz
RCA LINE OUT
Output 1200mV @ MAX.
SD or USB PLAYBACK
System MP3 audio system.
Frequency characteristics 20Hz -100Hz <=5dB
10KHz-20KHz <=5dB.
Signal to noise (SD & USB) 50dB [1KHz] .
If at any time in the future you should need to dispose of this product please note that: Waste
electrical products should not be disposed of with household waste. Please recycle where facilities
exist. Check with your local authority or retailer for recycling advice. (Waste Electrical and
Electronic Equipment Directive)
