3
(5)Press the SELECT button;
(6) Press Tune up or down until the display says “Wired/Wireless”;
(7) Press the SELECT button;
(8) Press Tune up or down until your appropriate equipment; there is Auto, Wired Only, Wireless
Only Options.
If you select Auto, it will be select automatically.
If you select Wired Only, It will be only used for Wired Ethernet.
You should make sure the Wired Ethernet end has been plugged into the RJ45 socket ;
Note: There are 2 LEDs in the RJ45 socket of Wired Ethernet , The green color indicate the network
link, the orange one indicate the network act ;
If you select Wireless Only, It will be only used for Wireless Wi-Fi connection.
(8) When the ESSID for the access point you want to connect to be displayed on the screen, press
the SELECT button. You might need to enter the correct WEP(Wired Equivalent Privacy) or
WPA(Wi-Fi Protected Access) code .
If your network is not configured to need a WEP or a WPA code, the display will show:
If the screen displays:
Then the network is using one of the encryption systems:
Wired Equivalent Privacy (WEP) or Wi-Fi protected Access (WPA). You therefore need to enter the
correct WEP or WPA code into the radio for it to communicate with you network.
After 3 seconds the display goes into the code entry mode or press SELECT.
To enter the code, press Tune up or down to select each character of the code in turn, pressing the
SELECT button after each character.
Make sure the character you want is shown in the centre of the display to be able to select it.
WEP and WPA codes are case sensitive to upper and lower case characters so you must enter
them exactly.
After the final character, press Tune up or down to select END and press the SELECT key.
Wired/ Wireless
Network OK
Ecryption Key Required
<{}~ END <>0
Auto
To Next Page
