Make sure that the drive
belt is looped in the middle
of the circle. The drive belt
located too high or too low
in this circle may cause the
drive belt to fall off or speed
to be unstable.
2. Set the platter on the spindle.
Make sure the platter is fully seated on the spindle.
3. Place the belt on the motor pulley.
Align one of the platter openings with the motor pulley, and while
pulling both ends of the red ribbon that comes attached to the belt,
place the belt on the motor pulley, as per the diagram. When doing
this, be careful not to twist the belt.
