1. Gently push and turn the counterweight
onto the rear of the tonearm (with the dial
facing toward the front of the turntable).
2. Pull the protector straight forward to
remove it.
NOTE: Applying a downward force may
cause the stylus to come off the body.
Only low volume is output if the stylus has
come off, or is about to come off, so refer to
"Replacing the stylus" to reattach the stylus
correctly.
3. Remove the tie-wrap and unlock the tonearm.
4. Lower the tonearm lift lever and position the cartridge in the space
between the tonearm rest and platter.
5. Carefully rotate the counterweight until the tonearm achieves a
neutral balance. The tonearm should return to this balanced
position if it is moved up or down. This adjustment must be done
carefully.
6. Once the tonearm is correctly balanced, return the tonearm to its
rest. Without moving the position of the counterweight, gently
To Next Page
