LENCO LS-50TQ User Manual

12
2. TECHNICAL SPECIFICATIONS
Lenco
Turntable
LS-50
Type
Belt drive full manual
Drive Motor
DC motor
Speed
33 1/3 rpm, 45 rpm, 78 rpm
Wow and flutter
<0.35%
Turntable platter
300mm
Cartridge
Type
Ceramic cartridge 402-M208-015
Stylus
0.7 mil
Optimum tracking force
4-6 gram
Output
160-380mv(HP-4005)
Frequency response
-28db(10KHz)
Crosstalk
10db(1KHz)
Signal-to-noise ratio(S/N)
40db
General
ADAPTOR
input AC100-240V~50/60Hz0.5A
output DC12V1000mA
PRODUCT
DC12V1000mA
Audio output (Line Out)
400-600mv
Power consumption
12W
Dimension
410x330x118MM
Net weight
approx 3.18KGS--LS-50WD
approx 3.43KGS--LS-50GY
Power supply adaptor
Manufacturer: SHENZHEN SHI GUANGKAIYUAN TECHNOLOGY.,LTD.
Model number: GKYPS0100120EU1
Use only original AC adaptor
Use only the power supply listed in the user instructions
