12
CAUTION!
Risk of injury!
Opening the device can cause injuries.
Fault
Possible cause/action
No function
- If the device has been disrupted by a thunderstorm,
a static charge or another external factor, follow this
procedure to resolve the problem: Power off this
device and power on it again 10 seconds later.
- Disconnect the supplied adapter and then plug it in
again.
No sound
- The volume may be set too low or in mute mode.
- In Bluetooth mode: Set the volume of the external
device to the maximum and then control the volume
by using “Rotary button (07)”.
No/bad radio
reception
- If necessary, select another location to improve the
radio signal.
- Adjust the telescopic antenna to optimize the radio
reception.
No Bluetooth®
connection
- Take care to ensure that all settings have been made
correctly on all devices. The Bluetooth® function
may be deactivated on the external device. (re)
activate it, if necessary.
- Check whether the device to be connected is
switched on and is in search mode.
12. Specification
Device: Portable Bluetooth DAB Radio
Unit Dimension
155 (L) *90. 5mm (W) *32mm (H)
Unit Weight
285g
Display
Type
LED Display
Size
48mm x 13mm
Bluetooth
Specification
V5.0
Supported Profile
A2DP, AVRCP, HSP
Connection Distance
In 10 meters (open
area)
Power
Class II
DAB
Tuning Range
Band III; 174.928MHz
– 239.2MHz
Preset Memory
30 stations
FM
Tuning Range
87.5 - 108MHz
Stereo/Mono
Selectable
Preset Memory
30 stations
Antenna
telescopic type
Audio Output Power
Output Power
1X3W RMS
Freq. Responses
80Hz to 16, 000Hz
Power Source Input
Micro USB Port
PC’s USB port Power or DC 5V, 1A
Built-in-Battery
Lithium 3.7V 2000mAh
Operating Temperature
0-40°C
Power supply adaptor (For EU only)
Manufacturer: Shenzhen Tianyin Electronics Co. , Ltd.
Model number: TPA-67B050100VU01
Input voltage : 100-240V
Input AC frequency : 50/60Hz
Output voltage : 5V
Output current : 1.0A
Output Power : 5W
Average active efficiency : ≥73.63%
No load Power consumption : 0.1W
Use only the power supply listed in the user instructions
Guarantee
Lenco offers service and warranty in accordance to European law, which
means that in case of repairs (both during and after the warranty period) you
should contact your local dealer.
Important note: It is not possible to send products that need repairs to Lenco
directly.
Important note: If this unit is opened or accessed by a non-official service
center in any way, the warranty expires.
This device is not suitable for professional use. In case of professional use, all
warranty obligations of the manufacturer will be voided.
Disclaimer
Updates to Firmware and/or hardware components are made regularly.
Therefore some of the instruction, specifications and pictures in this
documentation may differ slightly from your particular situation. All items
described in this guide for illustration purposes only and may not apply to
particular situation. No legal right or entitlements may be obtained from the
description made in this manual.
Disposal of the Old Device
This symbol indicates that the relevant electrical product or
battery should not be disposed of as general household waste
in Europe. To ensure the correct waste treatment of the
product and battery, please dispose them in accordance to
