8
to enter the auto update sub-menu.
● Rotate “Rotary button (07)” or Press“ (03) ” or “ (04) ”button to
select auto update mode from the menu. You can select <update from
any>, <update from FM>, <update from DAB> or <No update>, Press the
“Rotary button (07)” to confirm the update mode setting.
● If you do not want to save the settings, press the “MENU/INFO (02)”
button to cancel the settings.
7.4. Backlight
7.4.1. After entering System settings menu, rotate the “Rotary button (07)”
or Press “ (03) ” or “ (04) ”button to select <Backlight> from
the menu. Press the “Rotary button (07)” to enter the Backlight
settings sub-menu.
7.4.2. Timeout
● Rotate the “Rotary button (07)” or Press “ (03) ” or “ (04) ”button
to select <Timeout> from the menu, Press the “Rotary button (07) ” to
enter the Timeout sub-menu.
● Rotate the “Rotary button (07)” or Press “ (03) ” or “ (04) ”button
to select the duration from menu, you can select <10 sec>, <20 sec>, <30
sec>, <45 sec>, <60 sec>, <90 sec>, <120 sec>, <180 sec> and <on>, Press
the “Rotary button (07) ” to confirm the duration time.
● If you do not want to save the settings, press the “MENU/INFO (02) ”
button to cancel the settings.
7.4.3. Dim Level
● Rotate the “Rotary button (07)” or Press “ (03) ” or “ (04) ”button
to select the <Dim level> from the menu. Press the “Rotary button (07)”
to enter the Dim level sub-menu.
● Rotate the “Rotary button (07)” or Press “ (03) ” or “ (04) ”button
to select Dim level from menu. You can select <Medium>, <Low>, <High>,
Press “Rotary button(07)” to confirm the Dim level setting.
● If you do not want to save the settings, press the “MENU/INFO (02) ”
button to cancel the settings.
7.4.4. On Level
● Rotate the “Rotary button (07) ” or Press “ (03) ” or “ (04) ”button
to select the <On level> from the menu. Press the “Rotary button (07) ” to
enter the On level sub-menu.
● Rotate the “Rotary button (07) ” or Press “ (03) ” or “ (04) ” button
to select the On level from the menu. You can select <Medium>, <Low>,
<High>, Press the “Rotary button (07) ” to confirm the On level setting.
● If you do not want to save the settings, press the “MENU/INFO (02) ”
button to cancel the settings.
7.5. Language
7.5.1. After entering System settings menu, rotate the “Rotary button (07) ”
or Press “ (03) ” or “ (04) ”button to select <Language> from
the menu. Press the “Rotary button (07) ” to enter the Language
settings menu.
7.5.2. Rotate the “Rotary button (07) ” or Press “ (03) ” or “
(04) ”button to select the language you want and Press the “Rotary
button (07) ” to confirm the language settings
● If you do not want to save the settings, press the “MENU/INFO (02)”
button to cancel the settings.
7.6. Factory Reset
In some circumstances the device needs to be reset to factory defaults
NOTE: All settings/presets will be lost when doing a factory reset.
7.6.1. After entering the System settings mode, Rotate the “Rotary button
(07)” or Press “ (03)” or “ (04)”button to select <Factory Reset>
from the menu.
7.6.2. Rotate the “Rotary button (07)” or Press “ (03) ” or “
(04) ”button to select <Yes> or <No> and Press the “Rotary button
(07) ” to confirm the selection.
● If you do not want to save the settings, press the “MENU/INFO (02) ”
button to cancel the settings.
7.7. Software upgrade
Connect the Micro USB cable to the “Charging USB port (12) ” and the
supplied external 5V 1A USB charger, and then use other micro USB cable
connect to “USB port (13) ” and other end connect to your PC to enable the
upgrade mode.
7.7.1. After entering the System settings menu, rotate the “Rotary button
(07) ” or Press “ (03) ” or “ (04) ”button to select <Software
upgrade> from the menu. Press the “Rotary button (07) ” to enter
Software upgrade menu.
7.7.2. Rotate the “Rotary button (07) ” or Press “ (03) ” or “
(04) ”button to select <Yes> or <No> and Press the “Rotary button
(07) ” to confirm the selection.
7.7.3. If you do not want to upgrade the FW, press the “MENU/INFO (02) ”
button to cancel.
NOTE: Software update can only be done if you have received an approved
update file from our service department. Upgrade with other software files
will make a Permanent damage to this apparatus.
7.8. SW version
7.8.1. After entering the System settings menu, Rotate the “Rotary button
(07) ” or Press “ (03) ” or “ (04) ”button to select <SW version>
from the menu. Press the “Rotary button (07) ” to display the SW
version information.
7.8.2. Press “MENU/INFO(02)” button to return to previous menu.
8. How do use the DAB Radio
8.1. General functions
8.1.1. Switching On and Off
● Short press the “ /MODE” button to power on the Lenco PDR-040. Then
short press “ /MODE” button to select DAB mode.
8.1.2. Adjusting the volume
