Page 3
SPECIFICATIONS
Gas
Heating
Performance
Model No. EL296UH110XV60C EL296UH135XV60D
1
AFUE 96% 96%
High
Fire
Input - Btuh 110,000 132,000
Output - Btuh 106,000 126,000
Temperature rise range - °F 45 - 75 55 - 85
Gas Manifold Pressure (in. w.g.)
Nat. Gas / LPG/Propane
3.5 / 10.0 3.5 / 10.0
Low
Fire
Input - Btuh 72,000 86,000
Output - Btuh 70,000 84,000
Temperature rise range - °F 35 - 65 40 - 70
Gas Manifold Pressure (in. w.g.)
Nat. Gas / LPG/Propane
1.7 / 4.5 1.7 / 4.5
High static - in. w.g. Heating 0.8 0.8
Cooling 1.0 1.0
Connections
in.
Intake / Exhaust Pipe (PVC) 2 / 2 2 / 2
Gas pipe size IPS 1/2 1/2
Condensate Drain Trap (PVC pipe) - i.d. 3/4 3/4
with furnished 90° street elbow 3/4 slip x 3/4 Mipt 3/4 slip x 3/4 Mipt
with eld supplied (PVC coupling) - o.d. 3/4 slip x 3/4 MPT 3/4 slip x 3/4 MPT
Indoor
Blower
Wheel nominal diameter x width - in. 11 x 11 11 x 11
Motor output - hp 1 1
Tons of add-on cooling 3-5 3-5
Air Volume Range - cfm 850 - 2125 950 - 2250
Electrical Data Voltage 120 volts - 60 hertz - 1 phase
Blower motor full load amps 12.8 12.8
Maximum overcurrent protection 20 20
Shipping Data lbs. - 1 package 174 188
NOTE - Filters and provisions for mounting are not furnished and must be eld provided.
1
Annual Fuel Utilization Eciency based on DOE test procedures and according to FTC labeling regulations. Isolated combustion system rating for non-weatherized
furnaces.
