BLOWER DATA
EL296UH090XV48C BLOWER PERFORMANCE (less lter)
SINGLE SIDE RETURN AIR
0 through 0.8 in. w.g. (Heating) and 0 through 1.0 in. w.g. (Cooling) External Static Pressure Range
HEATING
1
Heating Speed
DIP Switch
Settings
First Stage Heating Speed - cfm Second Stage Heating Speed - cfm
+24% 1400 1570
+18% 1380 1475
+12% 1310 1415
+6% 1255 1360
Factory Default 1210 1285
–6% 1125 1260
–12% 1080 1150
–18% 990 1115
COOLING
1
Cooling Speed
DIP Switch
Settings
First Stage Cooling Speed - cfm Second Stage Cooling Speed - cfm
Low Medium-Low Medium-High
2
High Low Medium-Low Medium-High
2
High
+ 820 1005 1135 1290 1140 1340 1525 1725
Factory Default 755 880 1025 1150 1040 1235 1395 1565
– 680 815 925 1065 910 1120 1275 1400
1
Cooling and heating speeds are based on a combination of DIP switch settings on the furnace control. Refer to Installation Instructions for specic DIP Switch Settings.
2
Factory default setting.
NOTES - The e󰀨ect of static pressure is included in air volumes shown.
First stage HEAT is approximately 91% of the same second stage HEAT.
First stage COOL (two-stage air conditioning units only) is approximately 70% of the same second stage COOL speed position.
Continuous Fan Only speed is selectable at 28% and 38% of the selected second stage cooling speed - minimum 380 cfm.
Lennox iHarmony
®
Zoning System Applications - Minimum blower speed is 380 cfm.
EL296UH090XV48C BLOWER MOTOR WATTS (COOLING)
1
Cooling Speed
DIP Switch
Settings
Motor Watts @ Various External Static Pressures - in. wg.
First Stage Second Stage
0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0
+ Setting
Cooling
Speed
Low 43 65 85 96 119 134 156 179 199 102 131 155 189 216 249 282 304 331 359 387
Med-low 66 95 113 140 164 189 212 242 268 173 196 242 271 306 337 362 405 430 460 493
Med-High 95 126 151 180 210 242 277 302 320 243 277 316 371 412 457 492 534 566 605 651
High 143 166 203 243 282 309 333 368 389 368 410 453 511 562 604 651 690 730 771 809
Factory Default
Cooling
Speed
Low 36 48 73 86 108 120 140 152 168 75 101 125 156 178 215 244 259 288 320 339
Med-low 52 75 95 110 130 161 176 201 216 129 154 190 218 257 295 322 346 377 404 434
Med-High 70 94 125 146 172 198 230 252 275 190 222 270 299 325 368 398 439 470 508 549
High 100 131 162 197 228 260 298 328 347 275 310 359 400 445 469 525 562 597 642 682
– Setting
Cooling
Speed
Low 32 45 58 80 97 110 121 133 154 62 87 109 129 152 173 199 221 250 266 295
Med-low 45 63 82 99 119 137 150 171 193 95 124 150 180 207 240 269 297 325 356 375
Med-High 55 82 101 119 145 167 192 213 239 148 177 205 244 286 309 346 370 402 431 467
High 76 101 137 160 188 218 245 271 302 198 239 274 308 349 384 426 471 500 542 576
