Lennox EL296UHV series Unit Information

Page 19
BLOWER DATA
EL296UH110XV48C BLOWER PERFORMANCE (less lter)
BOTTOM RETURN AIR
0 through 0.8 in. w.g. (Heating) and 0 through 1.0 in. w.g. (Cooling) External Static Pressure Range
HEATING
1
Heating Speed
DIP Switch
Settings
First Stage Heating Speed - cfm Second Stage Heating Speed - cfm
+24% 1470 1605
+18% 1450 1495
+12% 1385 1445
+6% 1295 1385
Factory Default 1225 1305
–6% 1160 1225
–12% 1090 1150
–18% 1035 1070
COOLING
1
Cooling Speed
DIP Switch
Settings
First Stage Cooling Speed - cfm Second Stage Cooling Speed - cfm
Low Medium-Low Medium-High
2
High Low Medium-Low Medium-High
2
High
+ 810 980 1085 1235 1100 1325 1530 1760
Factory Default 760 875 1010 1135 1025 1205 1405 1565
– 695 805 905 1040 920 1080 1260 1440
1
Cooling and heating speeds are based on a combination of DIP switch settings on the furnace control. Refer to Installation Instructions for specic DIP Switch Settings.
2
Factory default setting.
NOTES - The e󰀨ect of static pressure is included in air volumes shown.
First stage HEAT is approximately 91% of the same second stage HEAT.
First stage COOL (two-stage air conditioning units only) is approximately 70% of the same second stage COOL speed position.
Continuous Fan Only speed is selectable at 28% and 38% of the selected second stage cooling speed - minimum 380 cfm.
Lennox iHarmony
®
Zoning System Applications - Minimum blower speed is 380 cfm.
EL296UH110XV48C BLOWER MOTOR WATTS (COOLING)
1
Cooling Speed
DIP Switch
Settings
Motor Watts @ Various External Static Pressures - in. wg.
First Stage Second Stage
0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0
+ Setting
Cooling
Speed
Low 37 59 80 96 119 140 166 182 203 92 122 147 173 201 230 255 286 313 340 369
Med-low 57 85 105 132 153 175 206 230 256 136 170 204 237 275 311 351 382 411 447 481
Med-High 87 115 141 167 195 221 245 277 302 215 239 289 338 385 416 452 494 523 562 600
High 115 152 175 213 240 275 309 338 376 331 378 427 465 514 559 589 658 693 738 793
Factory Default
Cooling
Speed
Low 33 53 72 92 111 129 146 167 191 69 94 118 145 168 201 225 250 272 297 321
Med-low 40 70 85 110 135 155 185 200 230 108 145 166 201 226 262 292 321 358 383 417
Med-High 64 91 113 140 162 191 218 242 266 166 199 240 275 315 345 387 418 456 490 526
High 96 129 151 179 205 239 264 294 322 232 267 310 353 393 434 471 506 546 589 625
– Setting
Cooling
Speed
Low 27 45 65 83 99 116 139 155 176 49 75 97 117 144 171 191 219 246 268 286
Med-low 38 59 81 98 119 137 158 184 202 89 117 144 169 197 223 248 279 305 333 360
Med-High 46 73 93 115 142 164 188 211 241 120 156 182 219 249 286 321 351 385 415 449
High 71 97 122 149 172 205 228 254 277 184 217 256 300 337 369 409 443 483 517 554

Lennox EL296UHV series Specifications

General

Efficiency	Up to 96% AFUE
Stages of Heating	Two-Stage
Blower Motor	Variable Speed
Energy Star Certified	Yes
Heat Exchanger Warranty	Limited Lifetime Warranty
Sound Level	Quiet Operation
Fuel Type	Natural Gas
Parts Warranty	5-Year Limited Warranty
Heating Capacity	44, 000 to 132, 000 BTU/h
