Page 54
HEATING COMPONENTS
Intake Air Top Cap
Sensor
Rollout Switch
Rollout Switch
Burner Assembly
Ignitor
Manifold And Gas Orifices
Two-Stage Gas Valve
Burner Box Cover
FIGURE 15
