Lennox EL296UHV series User Manual

Page 2
EL296UHV Parts Identification
FIGURE 1
DURALOK
TM
HEAT
EXCHANGER
ASSEMBLY
BURNERS
BLOWER
MOTOR
GAS VALVE
AND MANIFOLD
COMBUSTION AIR
INDUCER
FLUE
COLLAR
TOP CAP
INTEGRATED
CONTROL
PRESSURE SWITCH
ASSEMBLY
AIR INTAKE COLLAR
ACCESS PANEL
NOTE - This manual is the property of the homeowner
and must be left with the equipment user.
Notice to Homeowner
This furnace is equipped with safety devices that protect
you and your property. If one or more of these devices is
activated, furnace operation will stop. If your home is left
unattended for an extended period of time, equipment op
eration must be checked periodically. If this is not possible,
the water supply to the house should be shut off and the
pipes should be drained. This will prevent problems associ
ated with a NO HEAT condition (frozen pipes, etc.)

Lennox EL296UHV series Specifications

General

Efficiency	Up to 96% AFUE
Stages of Heating	Two-Stage
Blower Motor	Variable Speed
Energy Star Certified	Yes
Heat Exchanger Warranty	Limited Lifetime Warranty
Sound Level	Quiet Operation
Fuel Type	Natural Gas
Parts Warranty	5-Year Limited Warranty
Heating Capacity	44, 000 to 132, 000 BTU/h
