Lennox EL296UHVX Series Installation Instructions

Page 52
Blower Data
EL296UH090XV36C BLOWER PERFORMANCE (less lter)
BOTTOM RETURN AIR
0 through 0.8 in. w.g. (Heating) and 0 through 1.0 in. w.g. (Cooling) External Static Pressure Range
HEATING
1
Heating Speed
DIP Switch
Settings
First Stage Heating Speed - cfm Second Stage Heating Speed - cfm
+24% 1215 1300
+18% 1140 1240
+12% 1100 1170
+6% 1020 1115
Factory Default 965 1070
–6% 915 970
–12% 850 925
–18% 805 855
COOLING
1
Cooling Speed
DIP Switch
Settings
First Stage Cooling Speed - cfm Second Stage Cooling Speed - cfm
Low Medium-Low Medium-High
2
High Low Medium-Low Medium-High
2
High
+ 625 710 830 950 875 1040 1210 1360
Factory Default 565 670 760 860 800 945 1100 1245
– 520 610 685 785 720 840 970 1115
EL296UH110XV48C BLOWER PERFORMANCE (less lter)
BOTTOM RETURN AIR
0 through 0.8 in. w.g. (Heating) and 0 through 1.0 in. w.g. (Cooling) External Static Pressure Range
HEATING
1
Heating Speed
DIP Switch
Settings
First Stage Heating Speed - cfm Second Stage Heating Speed - cfm
+24% 1470 1605
+18% 1450 1495
+12% 1385 1445
+6% 1295 1385
Factory Default 1225 1305
–6% 1160 1225
–12% 1090 1150
–18% 1035 1070
COOLING
1
Cooling Speed
DIP Switch
Settings
First Stage Cooling Speed - cfm Second Stage Cooling Speed - cfm
Low Medium-Low Medium-High
2
High Low Medium-Low Medium-High
2
High
+ 810 980 1085 1235 1100 1325 1530 1760
Factory Default 760 875 1010 1135 1025 1205 1405 1565
– 695 805 905 1040 920 1080 1260 1440
1
Cooling and heating speeds are based on a combination of DIP switch settings on the furnace control. Refer to Installation Instructions for specic DIP Switch Settings.
2
Factory default setting.
NOTES - The effect of static pressure is included in air volumes shown.
First stage HEAT is approximately 91% of the same second stage HEAT.
First stage COOL (two-stage air conditioning units only) is approximately 70% of the same second stage COOL speed position.
Continuous Fan Only speed is selectable at 28%, 38%, 70% and 100% of the selected second stage cooling speed - minimum 380 cfm.
Lennox iHarmony
®
Zoning System Applications - Minimum blower speed is 250 cfm for EL296UH090XV60C and 380 cfm for EL296UH110XV48C.
