BLOWER DATA
EL296UH090XV48C BLOWER PERFORMANCE (less lter)
SINGLE SIDE RETURN AIR WITH OPTIONAL RETURN AIR BASE
0 through 0.8 in. w.g. (Heating) and 0 through 1.0 in. w.g. (Cooling) External Static Pressure Range
HEATING
1
Heating Speed
DIP Switch
Settings
First Stage Heating Speed - cfm Second Stage Heating Speed - cfm
+24% 1430 1565
+18% 1400 1500
+12% 1330 1410
+6% 1260 1380
Factory Default 1195 1305
–6% 1135 1275
–12% 1065 1180
–18% 990 1095
COOLING
1
Cooling Speed
DIP Switch
Settings
First Stage Cooling Speed - cfm Second Stage Cooling Speed - cfm
Low Medium-Low Medium-High
2
High Low Medium-Low Medium-High
2
High
+ 840 955 1120 1280 1160 1360 1530 1740
Factory Default 775 910 1010 1170 1060 1240 1400 1590
– 695 815 930 1045 925 1130 1295 1440
1
Cooling and heating speeds are based on a combination of DIP switch settings on the furnace control. Refer to Installation Instructions for specic DIP Switch Settings.
2
Factory default setting.
NOTES - The e󰀨ect of static pressure is included in air volumes shown.
First stage HEAT is approximately 91% of the same second stage HEAT.
First stage COOL (two-stage air conditioning units only) is approximately 70% of the same second stage COOL speed position.
Continuous Fan Only speed is selectable at 28% and 38% of the selected second stage cooling speed - minimum 380 cfm.
Lennox iHarmony
®
Zoning System Applications - Minimum blower speed is 380 cfm.
EL296UH090XV48C BLOWER MOTOR WATTS (COOLING)
1
Cooling Speed
DIP Switch
Settings
Motor Watts @ Various External Static Pressures - in. wg.
First Stage Second Stage
0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0
+ Setting
Cooling
Speed
Low 40 60 80 96 115 133 151 176 192 94 127 151 180 207 241 274 303 340 358 381
Med-low 58 87 108 132 158 188 212 240 264 166 195 233 269 300 328 356 394 426 455 496
Med-High 91 126 145 169 205 228 255 288 320 234 273 314 354 403 431 484 514 571 599 632
High 134 163 195 231 264 297 320 359 381 337 378 426 470 518 557 604 654 684 722 768
Factory Default
Cooling
Speed
Low 36 47 70 88 103 120 139 146 167 75 100 130 149 183 212 238 260 293 315 337
Med-low 51 75 93 115 135 158 187 201 222 132 156 192 220 259 284 319 343 376 404 423
Med-High 59 92 112 141 166 200 228 259 281 183 215 262 284 315 348 387 427 464 494 523
High 97 130 156 191 215 256 283 310 343 253 292 331 379 414 462 497 546 575 613 661
– Setting
Cooling
Speed
Low 26 41 55 73 88 104 120 134 149 56 84 104 123 149 174 199 224 248 268 290
Med-low 41 62 79 98 117 132 154 172 195 94 122 146 177 208 239 264 295 320 352 368
Med-High 50 75 95 120 147 164 187 209 243 140 170 197 234 263 301 327 357 377 412 453
High 72 102 125 154 178 208 234 262 293 196 235 264 302 332 377 413 441 482 518 548
