Page 18
BLOWER DATA
EL296UH090XV60C BLOWER PERFORMANCE (less lter)
SINGLE SIDE RETURN AIRAir volumes in bold require Optional Return Air Base and eld fabricated transition to accommodate
20 x 25 x 1 in. air lter in order to maintain proper air velocity.
0 through 0.8 in. w.g. (Heating) and 0 through 1.0 in. w.g. (Cooling) External Static Pressure Range
HEATING
1
Heating Speed
DIP Switch
Settings
First Stage Heating Speed - cfm Second Stage Heating Speed - cfm
+24% 1445 1920
+18% 1385 1875
+12% 1275 1735
+6% 1245 1600
Factory Default 1155 1565
–6% 1070 1480
–12% 975 1400
–18% 920 1275
COOLING
1
Cooling Speed
DIP Switch
Settings
First Stage Cooling Speed - cfm Second Stage Cooling Speed - cfm
Low Medium-Low Medium-High
2
High Low Medium-Low Medium-High
2
High
+ 1040 1225 1380 1550 1555 1715 1920 2135
Factory Default 960 1085 1225 1415 1430 1565 1790 1980
840 990 1085 1250 1280 1450 1580 1790
1
Cooling and heating speeds are based on a combination of DIP switch settings on the furnace control. Refer to Installation Instructions for specic DIP Switch Settings.
2
Factory default setting.
NOTES - The e󰀨ect of static pressure is included in air volumes shown.
First stage HEAT is approximately 91% of the same second stage HEAT.
First stage COOL (two-stage air conditioning units only) is approximately 70% of the same second stage COOL speed position.
Continuous Fan Only speed is selectable at 28% and 38% of the selected second stage cooling speed - minimum 450 cfm.
Lennox iHarmony
®
Zoning System Applications - Minimum blower speed is 450 cfm.
EL296UH090XV60C BLOWER MOTOR WATTS (COOLING)
1
Cooling Speed
DIP Switch
Settings
Motor Watts @ Various External Static Pressures - in. wg.
First Stage Second Stage
0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0
+ Setting
Cooling
Speed
Low 66 95 123 147 173 204 233 260 290 241 273 315 357 405 433 466 519 547 584 620
Med-low 108 139 173 210 248 283 315 342 376 332 374 428 489 518 568 631 665 719 762 813
Med-High 159 192 233 272 314 359 386 421 457 518 557 601 675 713 772 819 873 913 949 987
High 241 273 315 357 405 433 466 519 547 713 750 822 866 946 986 1042 1085 1116 1144 1184
Factory Default
Cooling
Speed
Low 55 81 101 126 144 165 194 217 243 181 204 251 292 323 369 403 444 474 496 525
Med-low 75 109 134 159 194 226 255 282 316 270 304 361 389 433 473 506 547 602 642 665
Med-High 108 144 180 211 248 293 320 357 391 374 410 467 512 583 618 670 723 778 797 839
High 181 204 251 292 323 369 403 444 474 542 579 642 684 743 809 843 883 942 991 1019
– Setting
Cooling
Speed
Low 36 56 71 102 119 141 161 179 198 113 142 181 221 255 300 325 352 395 424 456
Med-low 57 84 110 133 151 175 210 234 257 170 208 209 303 343 382 417 455 489 509 552
Med-High 75 109 134 159 194 226 255 282 316 264 299 357 387 426 478 501 551 586 635 682
High 113 142 181 221 255 300 325 352 395 374 410 467 512 583 618 670 723 778 797 839
