Lennox ELITE EL296DFE User Manual

Page 2
Unit Dimensions - inches (mm)
AIR
EXHAUST AIR
OUTLET
COMBUSTION
AIR INTAKE
FLOW
2-1/16 (52)
GAS PIPING INLET
(Either Side)
RETURN AIR
OPENING
FRONT VIEW SIDE VIEW
TOP VIEW
A
B
C
3/4
(19)
27-3/4
(705)
19-1/4
(489)
9-1/8 (232) Right
6-9/16 (167) Left
2 (51)
Either Side
33
(838)
3/4
(19)
B
Supply
Air
Supply
Air
9/16
(14)
9/16
(14)
9/16
(14)
9/16
(14)
19-7/16
(494)
3/4
(19)
CONDENSATE
TRAP CONNECTION
5
(127)
6-7/16 (163)
Either Side
9 (229)
Either Side
2-1/4
(57)
(Either Side)
1-1/2 (38)
Front Panel
1-7/8 (48)
1 (25)
6-1/4
(157)
15
(381)
4-1/2
(114)
2-1/16
(52)
5-3/16
(132)
OPTIONAL LEFT SIDE
VENT LOCATION
(Kit Required)
ALTERNATE RIGHT SIDE
VENT LOCATION
(Parts Furnished)
ELECTRICAL INLET
(Either Side)
ELECTRICAL INLET
(Either Side)
Flue Condensate Trap Assembly
Furnished for external
field installation
on either side of unit.
(See installation instructions
for additional
information.)
7
(178)
Model No.
A
in. (mm)
B
in. (mm)
C
in. (mm)
EL296DF045XE36B
EL296DF070XE48B
17-1/2 (446) 16-3/8 (416) 16 (406)
EL296DF090XE48C
EL296DF110XE60C
21 (533) 19-7/8 (505) 19-1/2 (495)
