G24−200 HEAT SECTION AND CABINET
CABINET TOP
HEAT EXCHANGER ASSEMBLY*
LIMIT CONTROL*
LEFT SIDE PANEL*
PRESSURE SWITCH*
PRESSURE SWITCH*
FLUE BOX GASKET*
COMBUSTION
AIR BLOWER*
FLUE BOX*
IGNITOR*
SENSOR*
GAS VALVE*
(twostage)
BURNER RETENTION
BRACKET*
BURNER MTG
BRACKET*
FLAME ROLLOUT
SWITCH*
IGNITION CONTROL*
MAKE−UP BOX*
RIGHT SIDE PANEL
HEATING COMPARTMENT ACCESS
PANEL*
BLOWER COMPARTMENT
ACCESS PANEL
CENTER MULLION
REAR PANEL − TOP
REAR PANEL − BOTTOM
FLEXIBLE CONNECTOR
(THIS UNIT CONTAINS TWO HEAT SECTIONS. EACH
HEAT SECTION CONTAINS ONE OF THESE ITEMS.)
