Lennox HS29-024 User Manual

Page 6
HS29 SINGLE-PHASE UNIT CONTROL BOX
WITH NON−SCROLL COMPRESSOR
FIGURE 1
DUAL CAPACITOR
(C12)
START
CAPACITOR
(C7)
POTENTIAL
RELAY (K31)
COMPRESSOR
CONTACTOR
(K1)
GROUNDING
LUG
FAN
CAPACITOR (C1)
HS29 THREE-PHASE UNIT CONTROL BOX
TRANSFORMER
(T5) J" VOLT-
AGE UNITS ONLY
GROUNDING
LUG
COMPRESSOR
CONTACTOR
(K1)
HS29 SINGLE−PHASE UNIT CONTROL BOX
WITH SCROLL COMPRESSOR
FIGURE 2
DUAL CAPACITOR
(C12)
COMPRESSOR
CONTACTOR
(K1)
GROUNDING
LUG
CONTROL
BOX
SUCTION LINE
SERVICE VALVE
SUCTION
LINE
OUTDOOR
FAN/MOTOR
HS29 UNIT COMPONENTS
LIQUID LINE
SERVICE VALVE
DISCHARGE
LINE
FIGURE 3
COMPRESSOR
