Lennox KCB036 User Manual

Page 3
507348-04 12/2015
KG 024, 030, 036, 048, 060, 072, 074, 090 PARTS ARRANGEMENT (KGA090 shown)
EVAPORATOR
COIL
CONDENSER
FAN
CONDENSER
COIL
COMPRESSOR
CONDENSATE
DRAIN
FILTERS (4)
ECONOMIZER
(OPTIONAL)
GAS VALVE
BURNERS
COMBUSTION
AIR INDUCER
BLOWER
BLOWER
MOTOR
TB1 LOW VOLTAGE
TERMINAL BLOCK
REFRIGERANT
METERING DEVICE
KC 024, 030, 036, 048, 060, 072, 074, 090 PARTS ARRANGEMENT (KCA090 shown)
ELECTRIC HEAT
(Optional)
EVAPORATOR
COIL
CONDENSER
FAN
CONDENSER
COIL
COMPRESSOR
CONDENSATE
DRAIN
ECONOMIZER
(OPTIONAL)
BLOWER
BLOWER
MOTOR
TB1 LOW VOLTAGE
TERMINAL BLOCK
FILTERS (4)
REFRIGERANT
METERING DEVICE
