KG 092, 102, 120, & 150 PARTS ARRANGEMENT
EVAPORATOR
COIL
CONDENSER
FANS
CONDENSER
COIL
COMPRESSORS
CONDENSATE
DRAIN
FILTERS
(FOUR - 20 X 25 X 2”)
ECONOMIZER
(OPTIONAL)
BLOWER
MOTOR
GAS VALVE
BURNERS
COMBUSTION
AIR INDUCER
DISCONNECT /
CIRCUIT BREAKER
(FACTORY OR FIELD
INSTALLED OPTION)
BLOWER
INVERTER
(OPTIONAL)
KC 092, 102, 120, & 150 PARTS ARRANGEMENT
EVAPORATOR
COIL
CONDENSER
FANS
CONDENSER
COIL
COMPRESSORS
CONDENSATE
DRAIN
FILTERS
(FOUR - 20 X 25 X 2”)
ECONOMIZER
(OPTIONAL)
BLOWER
MOTOR
ELECTRIC
HEAT
DISCONNECT /
CIRCUIT BREAKER
(FACTORY OR FIELD
INSTALLED OPTION)
BLOWER
INVERTER
(OPTIONAL)
