LGH/LCH036, 048, 060, 072, 074
INSTALL BELT
FIGURE 24
1
2
3
4
TENSIONER
DRIVER
PULLEY
DRIVEN
PULLEY
ROTATE DRIVEN
PULLEY TO SEAT BELT
