Lennox LGM092U - Unit Components and Layout; Overall Parts Arrangement; Control Box Parts Arrangement

Page 12
PARTS ARRANGEMENT - 092U, 102U, 120U, 150U
FIGURE 1
UNIT
CONTROLLER
EVAPORATOR
COIL
CONDENSER
FANS
CONDENSER
COIL
COMPRESSORS
CONDENSATE
DRAIN
FILTERS
(FOUR - 20 X 25 X 2”)
ECONOMIZER
(OPTIONAL)
BLOWER
(DIRECT DRIVE)
GAS VALVE
BURNERS
COMBUSTION
AIR INDUCER
IGNITION
CONTROL
REHEAT COIL
(OPTIONAL)
COMPRESSOR
INVERTER
(BEHIND THE
HINGED PANEL)
WIRELESS
BOARD
WIFI
ANTENNA
(behind panel)
CONTROL BOX PARTS ARRANGEMENT
FIGURE 2
K1
K65
K191
BEHIND HINGED PANEL
T1
T43
HINGED PANEL IN CONTROL AREA
RETURN
PANEL
K2
W4
A55
A192
FL1
TB13
L43 or T3
T61
DISCONNECT BOX
F4/F61
F34
F10
F61
CB10,
GND
