Lennox LGT072 User Manual

Page 16
BLOWER DATA 0.5 HP
BLOWER TABLE INCLUDES RESISTANCE FOR BASE UNIT ONLY WITH DRY INDOOR COIL AND AIR FILTERS IN PLACE. FOR ALL UNITS ADD: 1 - Any factory installed options air resistance (heat section, economizer, etc.). 2 - Any eld installed accessories air resistance (duct resistance, di󰀨user, etc.).
Minimum Air Volume Required For Di󰀨erent Gas Heat Sizes: Standard Heat - 1075 cfm; Medium Heat - 1150 cfm; High Heat - 1500 cfm
See page 20 for wet coil and options/accessory air resistance data. DOWNFLOW
External
Static
Press.
in. w.g.
Percentage of Total Motor Torque
20% 30% 40% 50% 60% 70% 80% 90% 100%
Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM
0 811 50 415 994 82 473 1177 114 531 1319 154 579 1461 194 626 1564 236 663 1667 278 700 1804 349 753 1878 396 783
0.1 716 47 494 906 81 547 1095 115 599 1243 158 642 1391 200 685 1500 243 718 1608 286 751 1753 361 798 1833 409 824 0.2 631 49 570 827 85 618 1023 121 665 1176 165 704 1329 209 742 1442 254 772 1555 299 802 1708 375 843 1794 425 865 0.3 556 54 644 758 92 687 960 130 729 1118 176 764 1275 222 799 1392 268 825 1509 314 851 1668 392 888 1759 443 907 0.4 489 62 715 696 102 753 903 142 791 1065 189 822 1227 236 853 1347 284 877 1467 331 900 1632 410 932 1726 462 949 0.5 - - - - - - - - - - - - - - - - - - 851 155 851 1017 204 879 1183 253 906 1306 301 927 1429 349 948 1597 430 976 1693 481 991 0.6 - - - - - - - - - - - - - - - - - - 804 170 909 973 220 933 1141 269 957 1267 318 976 1392 367 994 1562 449 1019 1660 501 1032 0.7 - - - - - - - - - - - - - - - - - - 759 184 964 930 235 985 1101 286 1006 1228 336 1023 1355 385 1039 1527 467 1062 1624 519 1074 0.8 - - - - - - - - - - - - - - - - - - 716 199 1017 889 251 1036 1061 302 1054 1189 352 1069 1317 402 1083 1489 484 1103 1585 535 1115 0.9 - - - - - - - - - - - - - - - - - - 671 211 1067 845 264 1083 1019 316 1099 1148 366 1112 1276 416 1125 1447 499 1144 1540 549 1156 1.0 - - - - - - - - - - - - - - - - - - 625 222 1114 800 275 1128 974 327 1142 1102 378 1154 1230 428 1165 1400 510 1183 1489 559 1196 1.1 - - - - - - - - - - - - - - - - - - 576 230 1158 751 283 1170 925 336 1182 1052 387 1193 1179 437 1203 1345 518 1221 1430 566 1235 1.2 - - - - - - - - - - - - - - - - - - 521 234 1199 695 288 1210 869 341 1220 995 391 1230 1121 441 1240 1283 521 1258 1361 567 1273 1.3 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 806 340 1255 930 390 1265 1054 440 1274 1210 519 1293 1281 562 1311 1.4 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 734 335 1288 856 384 1297 977 433 1306 1126 510 1326 1188 552 1347
HORIZONTAL
External
Static
Press.
in. w.g.
Percentage of Total Motor Torque
20% 30% 40% 50% 60% 70% 80% 90% 100%
Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM
0 794 45 388 970 76 454 1146 107 519 1281 149 575 1416 191 630 1522 110 678 1627 293 726 1715 351 768 1802 408 810
0.1 709 44 460 895 78 519 1080 111 577 1223 155 627 1366 199 677 1477 251 721 1588 303 764 1681 362 804 1773 420 843 0.2 630 46 531 855 82 583 1019 117 634 1169 163 679 1318 208 723 1435 262 763 1552 315 803 1648 375 841 1743 434 878 0.3 556 51 602 759 88 646 961 125 690 1117 172 730 1273 219 769 1395 274 805 1516 328 841 1615 388 877 1714 448 912 0.4 486 58 671 696 97 709 906 135 746 1068 184 781 1230 232 815 1356 288 848 1481 343 880 1582 403 914 1683 463 948 0.5 420 66 740 637 107 771 854 147 802 1021 196 831 1188 245 860 1317 301 890 1446 357 919 1549 418 951 1652 478 983 0.6 - - - - - - - - - - - - - - - - - - 804 159 856 946 209 881 1147 259 905 1279 316 932 1410 372 958 1514 432 989 1618 492 1019 0.7 - - - - - - - - - - - - - - - - - - 756 172 910 932 223 930 1107 273 949 1241 330 973 1374 386 996 1478 446 1026 1582 506 1055 0.8 - - - - - - - - - - - - - - - - - - 709 185 962 888 236 978 1066 287 993 1201 344 1014 1336 400 1034 1440 460 1063 1544 519 1091 0.9 - - - - - - - - - - - - - - - - - - 663 197 1013 844 249 1025 1025 300 1036 1161 357 1054 1296 413 1072 1399 472 1100 1502 530 1127 1.0 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 982 313 1078 1118 369 1094 1254 424 1109 1355 482 1136 1456 540 1163 1.1 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 938 323 1119 1073 379 1133 1208 434 1146 1307 491 1172 1406 548 1198 1.2 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 892 332 1158 1026 387 1170 1159 441 1182 1255 497 1208 1351 553 1233 1.3 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 843 340 1197 975 393 1207 1106 446 1216 1198 501 1242 1290 555 1268 1.4 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 790 344 1234 920 396 1242 1049 448 1250 1137 501 1276 1224 553 1302

Lennox LGT072 Specifications

General

Brand	Lennox
Model	LGT072
Category	Air Conditioner
Language	English
