BLOWER DATA 1.5 HP
BLOWER TABLE INCLUDES RESISTANCE FOR BASE UNIT ONLY WITH DRY INDOOR COIL AND AIR FILTERS IN PLACE. FOR ALL UNITS ADD: 1 - Any factory installed options air resistance (heat section, economizer, etc.). 2 - Any eld installed accessories air resistance (duct resistance, di󰀨user, etc.).
Minimum Air Volume Required For Di󰀨erent Gas Heat Sizes: Standard Heat - 1075 cfm; Medium Heat - 1150 cfm; High Heat - 1500 cfm
See page 20 for wet coil and options/accessory air resistance data. HORIZONTAL
Total
Air
cfm
Total Static Pressure - in. w.g.
0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0 1.1 1.2 1.3
RPM Watts RPM Watts RPM Watts RPM Watts RPM Watts RPM Watts RPM Watts RPM Watts RPM Watts RPM Watts RPM Watts RPM Watts RPM Watts
400 708 16 793 37 872 53 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 600 835 46 918 65 1000 82 1077 95 1149 107 1221 109 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 800 981 75 1064 92 1144 109 1221 124 1294 139 1365 148 1434 154 1497 163 1555 179 1607 200 1656 226 1704 254 - - - - - -
1000 1166 105 1241 124 1315 141 1387 159 1454 176 1520 191 1582 207 1638 227 1689 252 1737 279 1783 308 1829 335 1873 362 1200 1374 142 1440 162 1506 182 1569 203 1630 224 1687 246 1739 271 1787 299 1832 330 1876 361 1920 391 1964 419 2007 444 1400 1591 183 1647 209 1701 235 1755 263 1806 291 1854 320 1899 351 1942 382 1984 412 2026 442 2068 469 2110 496 2153 520 1600 1778 258 1827 290 1876 323 1923 355 1970 386 2015 416 2059 444 2102 470 2144 494 2185 519 2227 545 2268 572 2309 600 1800 1973 352 2018 383 2063 415 2107 445 2151 476 2194 504 2237 531 2279 557 2319 584 2359 613 2397 645 2435 679 2471 713 2000 2182 437 2224 468 2265 499 2306 531 2346 563 2385 596 2424 630 2461 666 2496 705 2530 745 2564 786 2598 826 2631 866 2200 2388 540 2426 576 2464 613 2500 651 2536 691 2571 731 2605 774 2637 819 2668 863 2700 907 2732 949 2764 990 2795 1029 2400 2589 679 2624 719 2658 761 2691 803 2724 846 2756 890 2786 935 2816 980 2846 1025 2876 1068 2907 1109 2937 1149 2967 1188 2600 2787 845 2819 887 2850 930 2881 973 2911 1017 2941 1060 2970 1104 2999 1147 3028 1189 3057 1230 3087 1270 - - - - - - - - - - - - 2800 2983 1021 3013 1063 3042 1106 3070 1149 3099 1191 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
Total
Air cfm
Total Static Pressure - in. w.g.
1.4 1.5 1.6 1.7 1.8 1.9 2.0
RPM Watts RPM Watts RPM Watts RPM Watts RPM Watts RPM Watts RPM Watts
800 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
1000 1916 386 1957 408 1998 428 2037 447 2077 465 - - - - - - - - - - - - 1200 2049 468 2089 490 2128 510 2168 529 2207 549 2246 569 2285 591 1400 2194 543 2235 565 2274 588 2313 611 2350 637 2387 664 2423 694 1600 2349 627 2387 657 2423 688 2457 722 2490 757 2522 793 2554 830 1800 2506 749 2539 787 2571 825 2602 864 2632 903 2662 942 2692 981 2000 2663 906 2694 945 2725 985 2755 1024 2785 1063 2815 1101 2845 1138 2200 2826 1068 2857 1107 2887 1146 2916 1184 2946 1221 2975 1259 3005 1296 2400 2997 1227 3027 1266 3056 1304 3085 1342 - - - - - - - - - - - - - - - - - - 2600 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2800 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
