Page 22
THERMISTOR LOCATION
INDOOR COIL
(RT46, RT47)
BLUE
RT47
YELLOW
RT46
RT46 / RT47
Note - 156H units
do not use bypass
assemblies
FIGURE 9
THERMISTOR LOCATION
OUTDOOR COIL
(RT48, RT49)
BLUE
RT4
YELLOW
RT49
FIGURE 10
