Lennox LNWR53X Service Manual

Service Manual
Technical Information
8
Model LNWR59X
Product Code CC052020600_K79014
Power
Supply
Rated Voltage V~ 220-240
Rated Frequency Hz 50
Phases 1
Cooling Capacity W 6000
Heating Capacity W 5500
Cooling Power Input W 1810
Heating Power Input W 1660
Cooling Current Input A 7.87
Heating Current Input A 7.20
Rated Input W 2300
Rated Current A 11.62
Air Flow Volume(H/M/L) m
3
/h 850/800/750
Dehumidifying Volume L/h 2.2
EER W/W 3.31
COP W/W 3.31
Application Area m
2
27-42
Climate Type
T1
Isolation
I
Moisture Protection IP24
Permissible Excessive Operating Pressure for the Discharge Side MPa 4.3
Permissible Excessive Operating Pressure for the Suction Side MPa 2.5
Dimension (WXHXD) mm 660X428X770
Dimension of Carton Box (LXWXH) mm 736X860X500
Dimension of Package (LXWXH) mm 739X863X515
Net Weight kg 70.0
Gross Weight kg 75.0
Refrigerant R410A
Refrigerant Charge kg 1.45
Indoor Side
Fan Type Centrifugal
Fan Diameter Length(DXL) mm Φ201.5X109.5
Cooling Speed (H/M/L) r/min 1140/1040/940
Heating Speed (H/M/L) r/min /
Fan Motor Power Output W 200
Fan Motor RLA A 0.80
Fan Motor Capacitor μF 7
Electric Heating Power Input W /
Evaporator Form Aluminum Fin-copper Tube
Evaporator Pipe Diameter mm Φ7
Evaporator Row-n Gap mm 4-1.6
Evaporator Coil Length (LXDXW) mm 392X50.8X381
Swing Motor Model MP28ED
Swing Motor Power Output W 2.0
Fuse Current A 3.15
Sound Pressure Level (H/M/L) dB(A) 56/54/52
Sound Power Level (H/M/L) dB(A) 66/64/62
