10
FROM EDGE TO HOLE CENTER:50mm
FROM EDGE TO HOLE CENTER:70mm
BUBBLE
LEVEL
150
100
50
2
4
6
RECOMMAND
mm
inch
100
100
50
50
2
2
4
4
LIQUID
GAS
mm
inch
Indoor unit outline
Right rear side
refrigerant pipe inlet
2-1/2 (64) diameter
Left rear side
refrigerant pipe inlet
2-1/2 (64) diameter
44-7/8 (1140)
14-5/8
(371)
22-1/2 (570)
2-3/8 (60)
2-3/4
(70)
2 (51)
2
(51)
2 (51)
Figure 10. MWMC024S4S and MWMC030S4S Indoor Unit Wall Plate Dimensions - Inches (mm)
