Lennox MPB012S4S Service Manual

86
UP/DOWN Buttons
Increaseordecreasetheindoortemperatureintwodegreeincrements(maximum88°F,minimum62°F).
NOTE: Temperature cannot be adjusted in FAN mode.
NOTE: Press and hold and buttons together for 3 seconds to alternate the temperature display between the °C and °F
scale.
SWING Button
Usedtostoporstarthorizontallouverautoswingfeature.
ECONOMY Button
Maintainsthemostcomfortabletemperatureandsavesenergy.
RESET Button (Recessed)
ResetsControllertofactorysettings.Recessedtopreventtampering.
LOCK Button (Recessed)
LocksControllerbuttonstopreventtamperingwithsettings.
15.2.2. Display
1
2
1 12 1 12
MODE DISPLAY
FOLLOW ME INDICATOR
ON/OFF INDICATOR
TIME (ON/OFF)
TEMPERATURE DISPLAY
LOCK INDICATOR
FAN SPEED INDICATOR
