Lennox MPB036S4M-*P - M0 STAT61 Q-1 Wired Remote

85
15.2. M0STAT61Q-1 Wired Remote
MODE SELECTION
TIMERON
FOLLOWME
TIMER OFF
RESET
POWER
ADJUSTMENT UP
ADJUSTMENT DOWN
SWING
ECONOMY
FAN SPEED SELECTION
LOCK
TIMER
ON
TIMER
OFF
FOLLOW
ME
MODE
RESET
LOCK
FANSPEED
ECO
SWING
TEMP
Furnished with Ducted Indoor Units.
NOTE: Can be ordered separately for non-ducted indoor units.
Features
• Backlight-Allowseasyoperationinadarkroom.Thecontrollerlightswhenanybuttonispressedandremainslit
during control access.
• PermanentMemory-Maintainsclock,fanspeedandmodeofoperationsettingsfollowingpoweroutages.
• Dimensions(HxWxD)-4-3/4x4-3/4x7/8in.
• Additionalhardwareisfurnishedforinstallation.
• Wiring-Controlleruses5-wireshieldedcable(notfurnished)foreasylowvoltageconnectiontotheindoorunit.
15.2.1. Buttons
Mode
Selectsystemoperationmodes.Pushbuttontocyclethrougheachsetting.
AUTO COOL
DRY
HEAT
FAN
Power Button
Turnssystemonandoff.
FAN SPEED Button
Selectsfanspeed.Eachbuttonpresscyclesthroughthefollowingsettingsondisplay.
TIMER ON / TIMER OFF Buttons
• TIMERON(initiatesanauto-ontimesequence)andTIMEROFF(initiatesanauto-offtimesequence)canbeused
separatelyortogether.
• Eachpressofthebuttonincreasesthetimein30minuteincrementsupto10hours.Above10hourseachpressof
thebuttonwillincreasetheauto-timedsettingby60minutesupto24hours.
NOTE: To cancel, set timer to 0.0.
