Lennox PureAir PCO3S-16-16

5
Table 3. Approximate Air Flow Resistance
(Cabinet and Filter)
Capacity
(Tons)
Flow Rate
(CFM)
Pressure Drop (in. w.g.)
PCO3S-14-16 PCO3S-16-16 PCO3S-20-16
Low /
Variable
400 0.05 0.04 0.03
Low /
Variable
600 0.07 0.07 0.06
2 800 0.11 0.11 0.08
2.5 1000 0.15 0.15 0.11
3 1200 0.20 0.20 0.15
3.5 1400 0.25 0.25 0.18
4 1600 * 0.31 0.22
4.5 1800 * * 0.27
5 2000 * * 0.31
*Not recommended. Excessive system pressure drop can damage
HVAC system and reduce performance.
IMPORTANT
Do not wash UVA Lampholder / PCO cartridge. Soap and
water will destroy the titanium dioxide catalyst that coats
the cartridge surface.
IMPORTANT
Unpacking required.
Remove all protective packing material from the UVA
lamp (taped to the cabinet) and the titanium dioxide PCO
cartridge.
Packing material should be disposed of properly.
IMPORTANT
Possible odor emissions. Chemical reactions may
cause temporary odors after initial start-up or after lamp
replacement. Odor may also be present after paint,
cleaning solutions or hobby materials have been used in
the conditioned space.
Some occupants may experience irritation or discomfort
during this period. If the irritation or discomfort lasts longer
than 48 hours, the homeowner should be advised to
contact a Lennox dealer.
IMPORTANT
The cabinet should be installed so that the UVA lamp will
be in the horizontal position.
IMPORTANT
This system is NOT intended to be used for removal of
active mold growth or continuous sources of high levels of
chemicals in the air.
For existing mold growth, the mold must be properly
removed PRIOR to installation of the PureAir S air
purication system.
IMPORTANT
This appliance is intended for return air duct installation
only.
Improper installation may damage PureAir S air purication
system, HVAC system, or other equipment and may also
void warranty.
IMPORTANT
Healthy Climate
®
Carbon Clean 16
®
Filter cannot tolerate
direct exposure to UVA light.
Filter is protected by PCO cartridge shield.
