Page 2
Specifications and Electrical Data1
SPECIFICATIONS − SINGLE PHASE
General
Data
Model No. TPA024S4 TPA036S4 TPA048S4
Nominal kW 7 10.5 14.0
Connections
(sweat)
Liquid line o.d. − in. 3/8 3/8 3/8
Vapor line o.d. − in. 3/4 7/8 7/8
1
Refrigerant (R−410A) furnished 2.95 kg (6 lbs. 8 oz.) 2.86 kg (6 lbs. 5 oz.) 5.30 kg (11 lbs. 11 oz.)
Outdoor
Coil
Net face area
m
2
(sq. ft.)
Outer coil 1.41 (15.21) 1.41 (15.21) 1.96 (21.11)
Inner coil − − − 1.44 (15.50) 1.98 (21.31)
Tube diameter − in. 5/16 5/16 5/16
Number of rows 1 2 2
Fins per meter (inch) 866 (22) 866 (22) 866 (22)
Outdoor
Fan
Diameter − mm (in.) 457 (18) 457 (18) 559 (22)
Number of blades 3 4 4
Motor W (hp) 149 (1/5) 149 (1/5) 248 (1/3)
L/s (Cfm) 945 (2000) 965 (2042) 1530 (3242)
Rev / min 942 917 904
Watts 138 158 313
Shipping Data − kg (lbs.) 1 package 64 (140) 82 (180) 113 (250)
Electrical Data
Line voltage data − 50 hz − 1ph 220 / 240V 220 / 240V 220 / 240V
2
Maximum overcurrent protection (amps) 25 35 35
3
Minimum circuit ampacity 14.7 21.1 21.6
Compressor Rated load amps 10.9 16.0 15.9
Locked rotor amps 60.0 87.0 98.0
Power factor 1.1 1.1 1.7
Outdoor
Fan Motor
Full load amps 2.0 2.0 4.1
Locked rotor amps 1.9 1.9 4.1
NOTE − Extremes of operating range are plus 10% and minus 5% of line voltage.
1
Refrigerant charge sufficient for 4.6 m (15 ft.) length of refrigerant lines.
2
Heating Air Conditioning and Refrigeration type circuit breaker or fuse.
3
Refer to local codes to determine wire, fuse and disconnect size requirements.
