TS 6 to 20 Ton R−410A Air Conditioners / Page 6
Specifications 6 − 7.5 TON
General
Data
Model No. TSA072S4S
TSA090S4S
Nominal Size − Tons 6 7.5
Connections
(sweat)
Liquid line − in. (o.d) (1) 5/8 (1) 5/8
Suction line − in. (o.d) (1) 1−1/8 (1) 1−1/8
Refrigerant (R−410A) Factory installed holding charge
1
Field provided charge with 25 ft. line set 11 lbs. 0 oz. 16 lbs. 0 oz.
Condenser
Coil
Net face area − sq. ft. Outer coil 29.3 29.3
Inner coil − − − 28.4
Tube diameter − in. & no. of rows 3/8 − 1 3/8 − 2
Fins per inch 20 20
Condenser
Fan(s)
Diameter − in. & no. of blades (1) 24 − 3 (1) 24 − 4
Motor hp (1) 1/3 (1) 1/2
Total air volume − cfm 5100 5600
Rpm 1075 1075
Watts 430 580
ELECTRICAL DATA
Line voltage data − 60 hz − 3 phase 208/230V 460V 575V 208/230V 460V 575V
2
Maximum Overcurrent Protection (amps) 45 20 15 50 25 20
3
Minimum circuit ampacity 27 14 11 35 17 13
Compressor No. of Compressors 1 1 1 1 1 1
Rated load amps 19 9.7 7.4 25 12.2 9
Locked rotor amps 123 62 50 164 100 78
Condenser
FanMotor
(1 phase)
No. of motors 1 1 1 1 1 1
Full load amps 2.4 1.3 1 3 1.5 1.2
Locked rotor amps 4.7 2.4 1.9 6 3 2.9
NOTE − Extremes of operating range are plus and minus 10% of line voltage.
1
Refer to the Lennox Refrigerant Piping Manual to determine refrigerant charge required with longer length refrigerant lines.
2
HACR type circuit breaker or fuse.
3
Refer to National or Canadian Electrical Code manual to determine wire, fuse and disconnect size requirements.
