NOTES: For Temperatures and Capacities not shown in tables, see bulletin − Cooling Unit Rating Table Correction Factor Data in Miscellaneous Engineering Data section.
RATINGS 12.5 TON (DUAL CIRCUIT)
TS 6 to 20 Ton R−410A Air Conditioners / Page 26
AIR HANDLERS
COOLING CAPACITY − TSA150S4D (FIRST STAGE) with [TAA180S4D]
Entering
Wet Bulb
Tempera-
ture
Total
Air
Volume
Outdoor Air Temperature Entering Outdoor Coil
65_F (18_C) 75_F (24_C) 85_F (29_C) 95_F (35_C)
Total
Cooling
Capacity
Comp
Motor
kW
Input
Sensible To Total
Ratio (S/T)
Dry Bulb
Total
Cooling
Capacity
Comp
Motor
kW
Input
Sensible To Total
Ratio (S/T)
Dry Bulb
Total
Cooling
Capacity
Comp
Motor
kW
Input
Sensible To Total
Ratio (S/T)
Dry Bulb
Total
Cooling
Capacity
Comp
Motor
kW
Input
Sensible To Total
Ratio (S/T)
Dry Bulb
cfm L/s kBtuh kW
75_F
24_C
80_F
27_C
85_F
29_C
kBtuh kW
75_F
24_C
80_F
27_C
85_F
29_C
kBtuh kW
75_F
24_C
80_F
27_C
85_F
29_C
kBtuh kW
75_F
24_C
80_F
27_C
85_F
29_C
63_F
(17_C)
4000 1890 75.3 22.1 3.63 .68 .81 .96 72.8 21.3 4.05 .69 .83 .98 69.9 20.5 4.50 .70 .85 1.00 66.7 19.5 5.01 .71 .87 1.00
5000 2360 79.0 23.2 3.64 .72 .89 1.00 76.3 22.4 4.06 .73 .91 1.00 73.1 21.4 4.51 .75 .94 1.00 69.7 20.4 5.01 .77 .96 1.00
6000 2830 81.9 24.0 3.65 .77 .96 1.00 79.2 23.2 4.07 .78 .98 1.00 75.8 22.2 4.52 .81 1.00 1.00 72.6 21.3 5.02 .83 1.00 1.00
67_F
(19_C)
4000 1890 79.5 23.3 3.64 .54 .65 .77 76.9 22.5 4.06 .54 .66 .79 73.9 21.7 4.52 .55 .68 .81 70.7 20.7 5.02 .56 .69 .83
5000 2360 83.5 24.5 3.66 .56 .70 .85 80.7 23.7 4.07 .57 .71 .87 77.5 22.7 4.52 .58 .72 .89 73.8 21.6 5.02 .59 .74 .92
6000 2830 86.4 25.3 3.67 .59 .74 .92 83.3 24.4 4.07 .60 .76 .94 80.0 23.4 4.53 .61 .78 .97 76.1 22.3 5.03 .62 .80 .99
71_F
(22_C)
4000 1890 83.8 24.6 3.66 .41 .52 .63 81.0 23.7 4.07 .41 .53 .64 77.9 22.8 4.52 .42 .54 .65 74.5 21.8 5.03 .42 .54 .66
5000 2360 87.9 25.8 3.68 .42 .55 .67 85.0 24.9 4.08 .43 .56 .69 81.7 23.9 4.54 .43 .57 .70 78.0 22.9 5.03 .43 .58 .72
6000 2830 91.0 26.7 3.69 .43 .58 .72 87.7 25.7 4.09 .43 .59 .73 84.3 24.7 4.54 .44 .60 .75 80.5 23.6 5.05 .45 .61 .77
COOLING CAPACITY − TSA150S4D (SECOND STAGE) with [TAA180S4D]
Entering
Wet Bulb
Tempera-
ture
Total
Air
Volume
Outdoor Air Temperature Entering Outdoor Coil
85_F (29_C) 95_F (35_C) 105_F (41_C) 115_F (46_C)
Total
Cooling
Capacity
Comp
Motor
kW
Input
Sensible To Total
Ratio (S/T)
Dry Bulb
Total
Cooling
Capacity
Comp
Motor
kW
Input
Sensible To Total
Ratio (S/T)
Dry Bulb
Total
Cooling
Capacity
Comp
Motor
kW
Input
Sensible To Total
Ratio (S/T)
Dry Bulb
Total
Cooling
Capacity
Comp
Motor
kW
Input
Sensible To Total
Ratio (S/T)
Dry Bulb
cfm L/s kBtuh kW
75_F
24_C
80_F
27_C
85_F
29_C
kBtuh kW
75_F
24_C
80_F
27_C
85_F
29_C
kBtuh kW
75_F
24_C
80_F
27_C
85_F
29_C
kBtuh kW
75_F
24_C
80_F
27_C
85_F
29_C
63_F
(17_C)
4000 1890 139.7 40.9 9.00 .70 .85 1.00 133.4 39.1 10.03 .71 .87 1.00 126.3 37.0 11.18 .73 .91 1.00 118.4 34.7 12.49 .75 .94 1.00
5000 2360 146.3 42.9 9.03 .75 .94 1.00 139.5 40.9 10.03 .77 .96 1.00 132.4 38.8 11.19 .79 .99 1.00 124.5 36.5 12.51 .83 1.00 1.00
6000 2830 151.6 44.4 9.04 .81 1.00 1.00 145.1 42.5 10.04 .83 1.00 1.00 138.2 40.5 11.20 .86 1.00 1.00 130.7 38.3 12.52 .90 1.00 1.00
67_F
(19_C)
4000 1890 147.9 43.3 9.03 .55 .68 .81 141.3 41.4 10.03 .56 .69 .83 134.1 39.3 11 .20 .56 .70 .86 125.7 36.8 12.51 .58 .72 .90
5000 2360 155.0 45.4 9.04 .58 .72 .89 147.6 43.3 10.05 .59 .74 .92 140.3 41.1 11 .21 .60 .76 .95 131.4 38.5 12.53 .62 .80 .99
6000 2830 160.0 46.9 9.05 .61 .78 .97 152.3 44.6 10.07 .62 .80 .99 144.5 42.3 11 .23 .64 .83 1.00 135.3 39.7 12.55 .65 .87 1.00
71_F
(22_C)
4000 1890 155.9 45.7 9.04 .42 .54 .65 149.0 43.7 10.05 .42 .54 .66 141.6 41.5 11 .22 .43 .55 .68 133.2 39.0 12.53 .43 .57 .70
5000 2360 163.5 47.9 9.07 .43 .57 .70 156.0 45.7 10.07 .43 .58 .72 147.9 43.3 11 .22 .44 .59 .74 139.1 40.8 12.56 .44 .61 .77
6000 2830 168.6 49.4 9.07 .44 .60 .75 161.1 47.2 10.09 .45 .61 .77 152.7 44.8 11 .24 .44 .63 .80 143.5 42.1 12.58 .45 .64 .84
