TS − 3 to 5 Ton R−410A Air Conditioners / Page 17
ARI RATINGS
1
ARI Standard 210/240 Ratings
Ei
Cooling Capacity Efficiency
Total Unit
Indoor Unit Model No.
Expansion
Device
Btuh SEER EER
Total
Unit
Watts
D
ev
i
ce
tsa060s4 5 TON
Up-Flow Indoor Coils + Furnace Up−Flow Coils + Furnace
59,000 13.50 11.00 5225 CX34−49C−6F
4
G60UHV−60C−110 Factory TXV
59,000 13.50 11.00 5240 CX34−49C−6F
4
G71MPP−60C−110 Factory TXV
59,000 13.50 11.00 5240 CX34−49C−6F
4
G61MPV−60C−110 Factory TXV
59,500 13.50 11.00 5230 CX34−49C−6F
4
G60UHV−60C−090 Factory TXV
60,000 13.50 11.50 5180 CX34−60D−6F
4
G61MPV−60D−135 Factory TXV
60,000 13.50 11.50 5180 CX34−60D−6F
4
G71MPP−60D−135 Factory TXV
60,500 14.00 11.50 5180 CX34−62D−6F
4
G61MPV−60D−135 Factory TXV
60,500 14.00 11.50 5180 CX34−62D−6F
4
G71MPP−60D−135 Factory TXV
61,000 14.00 11.50 5175 CX34−60D−6F
4
G60UHV−60D−135 Factory TXV
61,500 14.00 11.50 5185 CX34−62D−6F
4
G60UHV−60D−135 Factory TXV
61,500 14.00 11.50 5240 CX34−62C−6F
4
G60UHV−60C−110 Factory TXV
61,500 14.00 11.50 5250 CX34−62C−6F
4
G61MPV−60C−110 Factory TXV
61,500 14.00 11.50 5250 CX34−62C−6F
4
G71MPP−60C−110 Factory TXV
62,000 13.50 11.50 5420 CX34−62C−6F
4
G61MPV−60C−090 Factory TXV
62,000 13.50 11.50 5420 CX34−62C−6F
4
G71MPP−60C−090 Factory TXV
62,000 14.00 11.50 5250 CX34−62C−6F
4
G60UHV−60C−090 Factory TXV
Down-Flow Indoor Coils Down−Flow Coils
58,500 13.00 11.00 5300
3
CR33−60D−F
2
91M02
Down-Flow Indoor Coils + Furnace Down−Flow Coils + Furnace
59,000 13.50 11.00 5365 CR33−60D−F
4
G61MPV−60D−135
2
91M02
59,000 13.50 11.00 5365 CR33−60D−F
4
G71MPP−60D−135
2
91M02
59,500 13.50 11.00 5410 CR33−60D−F
4
G60DFV−60D−135
2
91M02
Horizontal Indoor Coils Horizontal Coils
59,500 13.00 11.00 5310
3
CH33−60D−2F
2
91M02
60,000 13.00 11.00 5315
3
CH33−50/60C−2F
2
91M02
60,000 13.00 11.00 5315
3
CH33−62D−2F
2
91M02
60,500 13.50 11.00 5325
3
CH23−68
2
91M02
1
Certified in accordance with USE certification program which is based on ARI Standard 210/240; 95_F outdoor air temperature, 80_F db/67_F wb entering evaporator air
with 25 ft. of connecting refrigerant lines.
2
Factory installed RFC or expansion valve on indoor unit MUST be replaced with expansion valve kit (ordered separately) shown.
3
Blower must be capable of time−off blower delay. Indoor Blower Off Delay Relay (58M81) is recommended for field installation.
4
Blower control must be set for a time−off blower delay.
