Lennox XP17 - Page 37

XP17 - 2 to 5 Ton Heat Pump / Page 37
AHRI SYSTEM MATCHES
Model No.
Cooling
Capacity
SEER EER
Heat Capacity Heat COP
HSPF
(IV)
Coil or
Air Handler
Furnace
AHRI
Reference
High Low High Low
XP17-048-230 47,000 14.50 12.00 46,000 31,400 3.10 2.34 8.20 CH33-60D ML180UH135E60D 4666922
XP17-048-230 46,500 14.50 12.20 45,500 31,200 3.04 2.32 8.20 CH33-60D SL280UH135V60D 3894859
XP17-048-230 47,000 14.50 12.20 46,000 31,400 3.08 2.32 8.20 CH33-60D SLP98UH135XV60D 5136947
XP17-048-230 46,500 13.70 11.50 46,500 32,000 3.00 2.28 8.00 CH33-60D 3840271
XP17-048-230 48,000 14.50 12.20 46,000 31,800 3.14 2.34 8.20 CH33-62D EL195UH135XE60D 4693660
XP17-048-230 48,000 14.70 12.50 46,000 31,600 3.14 2.38 8.20 CH33-62D EL296UH135XV60D 5054832
XP17-048-230 48,500 15.00 12.50 46,000 31,600 3.16 2.38 8.50 CH33-62D ML180UH135E60D 4666923
XP17-048-230 48,000 15.00 12.50 46,000 31,400 3.14 2.38 8.20 CH33-62D SL280UH135V60D 3894860
XP17-048-230 48,000 14.70 12.50 46,000 31,600 3.14 2.38 8.20 CH33-62D SLP98UH135XV60D 5136948
XP17-048-230 48,000 14.00 11.70 46,500 32,000 3.04 2.30 8.20 CH33-62D 3840275
XP17-048-230 47,500 14.50 12.00 48,000 32,400 3.36 2.50 8.70 CR33-50/60 EL195DF090XE48C 4693661
XP17-048-230 47,500 14.50 12.20 47,500 32,200 3.36 2.50 8.70 CR33-50/60 EL196DF110XE60C 5535529
XP17-048-230 48,000 15.00 12.50 47,500 32,200 3.40 2.54 9.00 CR33-50/60 ML180DF110E60C 4666924
XP17-048-230 48,000 15.00 12.50 48,000 32,200 3.46 2.54 9.00 CR33-50/60 SL280DF090V60C 4016201
XP17-048-230 48,000 15.00 12.50 47,500 32,200 3.44 2.56 9.00 CR33-50/60 SL280DF110V60C 4016202
XP17-048-230 48,000 14.50 12.20 48,000 32,400 3.40 2.50 8.70 CR33-50/60 SLP98DF090XV60C 5136949
XP17-048-230 48,000 14.50 12.20 48,000 32,400 3.40 2.50 8.70 CR33-50/60 SLP98DF110XV60C 5136950
XP17-048-230 47,500 14.00 11.70 48,500 32,800 3.34 2.46 8.70 CR33-50/60 4016194
XP17-048-230 48,000 14.70 12.20 45,000 31,200 3.34 2.42 8.50 CX34-49 CBWMV-60C-100 4150374
XP17-048-230 48,500 14.70 12.20 45,000 31,200 3.30 2.42 8.50 CX34-49 EL195UH090XE48C 4693649
XP17-048-230 48,500 14.70 12.50 45,000 31,200 3.32 2.42 8.50 CX34-49 EL195UH110XE60C 4693650
XP17-048-230 48,500 14.70 12.20 45,000 31,200 3.30 2.40 8.50 CX34-49 EL296UH090XV48C 5054817
XP17-048-230 48,500 14.70 12.20 45,000 31,200 3.32 2.40 8.50 CX34-49 EL296UH090XV60C 5054818
XP17-048-230 48,500 14.70 12.20 45,000 31,200 3.30 2.40 8.50 CX34-49 EL296UH110V48C 4894981
XP17-048-230 48,500 14.70 12.50 45,000 31,200 3.32 2.42 8.50 CX34-49 EL296UH110XV60C 5054819
XP17-048-230 48,500 15.00 12.50 45,000 31,000 3.34 2.42 8.70 CX34-49 ML180UH090E60C 4666912
XP17-048-230 48,000 15.00 12.50 45,000 31,000 3.32 2.42 8.70 CX34-49 ML180UH110E60C 4666913
XP17-048-230 48,000 15.00 12.50 45,000 31,000 3.32 2.42 8.70 CX34-49 ML180UH110XE60C 4672129
XP17-048-230 48,500 15.00 12.50 45,000 31,000 3.36 2.42 8.70 CX34-49 SL280UH090V60C 3894843
XP17-048-230 48,500 15.00 12.50 45,000 31,000 3.36 2.42 8.70 CX34-49 SL280UH090XV60C 4235869
XP17-048-230 48,500 15.00 12.50 45,000 31,000 3.34 2.42 8.70 CX34-49 SL280UH110V60C 3894844
XP17-048-230 48,500 15.00 12.50 45,000 31,000 3.34 2.42 8.70 CX34-49 SL280UH110XV60C 4042024
XP17-048-230 48,500 14.70 12.20 45,000 31,200 3.30 2.40 8.50 CX34-49 SLP98UH090XV48C 5136933
XP17-048-230 48,500 14.70 12.20 45,000 31,200 3.32 2.40 8.50 CX34-49 SLP98UH090XV60C 5136934
XP17-048-230 48,500 14.70 12.50 45,000 31,200 3.32 2.42 8.50 CX34-49 SLP98UH110XV60C 5136935
XP17-048-230 47,500 14.00 11.70 46,000 31,800 3.30 2.40 8.50 CX34-49 3840197
XP17-048-230 47,000 14.20 12.00 45,000 31,400 3.38 2.44 8.70 CX34-60D EL195UH135XE60D 4693651
XP17-048-230 47,000 14.50 12.20 45,000 31,200 3.38 2.46 8.70 CX34-60D EL296UH135XV60D 5054823
XP17-048-230 47,500 14.50 12.20 45,000 31,200 3.40 2.48 8.70 CX34-60D ML180UH135E60D 4666914
XP17-048-230 47,000 14.50 12.20 45,000 31,000 3.40 2.46 8.70 CX34-60D SL280UH135V60D 3894847
XP17-048-230 47,000 14.50 12.20 45,000 31,200 3.38 2.46 8.70 CX34-60D SLP98UH135XV60D 5136939
XP17-048-230 47,000 13.70 11.50 46,500 32,000 3.00 2.28 8.20 CX34-60D 3840215
XP17-048-230 49,000 15.20 12.50 45,500 31,200 3.44 2.44 8.70 CX34-62C EL195UH090XE48C 4693652
XP17-048-230 49,000 15.20 12.50 45,500 31,200 3.46 2.46 8.70 CX34-62C EL195UH110XE60C 4693653
XP17-048-230 49,500 15.20 12.70 45,500 31,400 3.44 2.46 8.70 CX34-62C EL296UH090XV48C 5054820
XP17-048-230 49,500 15.20 12.70 45,500 31,200 3.44 2.44 8.70 CX34-62C EL296UH090XV60C 5054821
XP17-048-230 49,000 15.00 12.50 45,500 31,400 3.42 2.46 8.70 CX34-62C EL296UH110V48C 4894982
XP17-048-230 49,000 15.20 12.50 45,500 31,200 3.44 2.44 8.70 CX34-62C EL296UH110XV60C 5054822
XP17-048-230 49,500 15.50 12.70 45,500 31,000 3.48 2.46 8.70 CX34-62C ML180UH090E60C 4666915
XP17-048-230 49,000 15.20 12.70 45,000 31,000 3.42 2.46 8.70 CX34-62C ML180UH110E60C 4666916
NOTES:
Ratings are AHRI certied to AHRI Standard 210/240 (with 25 ft. of connecting refrigerant lines);
• Cooling Ratings - 95°F outdoor air temperature and 80 °F db/67° F wb entering indoor coil air.
• High Temperature Heating Ratings - 47° F db/43° F wb outdoor air temperature and 70 °F db entering indoor coil air.
• Low Temperature Heating Ratings - 17 °F db/15° F wb outdoor air temperature and 70 °F db entering indoor coil air.
All ratings include the use of a blower time delay relay (TDR). All Lennox variable-speed Furnaces and Air Handlers have time delay capabilities. Other Furnaces and Air
Handlers may require an optional time delay relay (58M81) for eld installation. See furnace or air handler specications to determine if relay is needed.
Also see TXV Substitution Table at the beginning of the Heat Pump AHRI System Matches section.
When used with gas furnaces, a dual-fuel control, a control system with dual-fuel capabilities (LZP-2 or LZP-4), or a thermostat with dual-fuel capabilities must be used
(order separately).
To convert HSPF from Region IV to Region V - Divide by 1.15.
