Page 17
ZCC PLUMBING AND COMPRESSOR CIRCUITS DETAIL
COMPRESSOR
B2
COMPRESSOR
B1
INDOOR COIL
STAGE 2
INDOOR COIL
STAGE 1
OUTDOOR
COIL STAGE 1
OUTDOOR
COIL STAGE 2
DRIERS
STG1
STG2
PRESSURE SWITCHES
S7
B2
B1
S4
(S16 120 only)
S4
(120 only)
FIGURE 4
