ZG/ZC 120S Normal Operating Pressures - 581155-01
Outdoor Coil Entering Air Temperature
65 F 75 F 85 F 95 F 105 F 115 F
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Circuit 1
102 252 105 296 108 323 111 369 114 420 117 476
110 257 113 297 115 327 125 389 122 422 125 478
124 271 133 311 132 337 136 385 138 429 142 490
136 281 145 329 151 350 155 397 160 447 164 501
Circuit 2
111 254 117 297 122 344 125 389 128 439 131 493
116 263 123 304 129 348 133 393 136 442 139 497
127 286 135 321 145 365 149 412 153 452 157 510
137 296 148 342 161 390 166 436 171 485 175 538
60
70
80
90
100
110
120
130
100 110 120130 140 150 160170
Suction Pressure (psig)
Outdoor Temperature (°F)
115°
105°
95°
85°
75°
65°
ZG/ZC 120S Charging Curves
Circuit 1
Circuit 2
180
50
