Page 38
TABLE 10
ECONOMIZER OPERATIONSUITABLE
Thermostat Demand
Damper Position
Mechanical Cooling
Unoccupied Occupied
󰀨 Closed Closed No
G Closed Minimum No
 Open* Open* No
 Open* Open* Stage 1

POWER EXHAUST FANS
ECONOMIZERP18
FIGURE 21
