1OrchidTiltStandbase2OrchidTiltStand
3Slidecover
4Memorymoduleshield
5Bottomcover
6I/Oshield
7Integratedcamera
8Computercover
9LCDpanel10Coverpresenceswitch(alsoknownasintrusion
switch)
11I/Obracket12Cardreader
13I/Oboard14Storagedrive
15Storagedrivebracket16Internalspeakers(2)
17Wi-Fiantennas(2)18VESAmountbracket
19Memorymodule20Heatsink
21Coin-cellbattery
22LEDboard
23Controlbuttonboard24Controlbuttonboardbezel
25Wi-Ficard
26Systemfan
27Systemboardshield
28Powercord
29Poweradapter
Partsonthesystemboard
Note:Forthepartsthataredisplayedonthefollowingfigurebutnotintroducedinthefollowingtable,see
“Frontview”onpage1and“Rearview”onpage3.
Figure4.Partsonthesystemboard
1Integratedcameraconnector2Memoryslot
3Coverpresenceswitchconnector(Intrusionswitch
connector)
4I/Oboardconnector
5Storagedriveconnector
6Internalspeakerconnector
7LCDconnector8Controlbuttonboardconnector
9LCDpanelconnector
10Wi-Ficardslot
11Systemfanconnector
6ThinkCentreX1UserGuide
