Step 4. Remove four screws and remove the storage drive from the storage drive bracket.

Figure 12. Remove four screws and remove the storage drive

Screw specifications

Number of screws

M3 x 3 4

Go to

https://support.lenovo.com/partslookup to look up the Lenovo part numbers of the following

replacement parts:

Storage drive

Storage drive bracket

Remove the heat sink

Make sure the following FRU (or CRU) has been removed.

“Remove the lower case” on page 28

IdeaPad 3 (14", 05), IdeaPad 3 (15", 05), and IdeaPad 3 (17", 05) Hardware Maintenance Manual
