Connectors and slots
• Combo audio jack
• USB Type-A connector × 2 (one connector with Always-On function)
• USB-C connector × 2
– Power input up to 95 W using the included power adapter
– Power output up to 5 V and 3 A
– USB data transfer rate up to 10 Gbps for USB 3.2 Gen 2
– DisplayPort 1.4a. Supports maximum output resolution of 5120 × 3200, at 60 Hz frame
rate and color depth of 24 bpp (bits per pixel).
• HDMI 2.0 connector
• microSD card slot
Note: Data rates and performance ratings are dependent on connected devices and cables if
they are used. For DisplayPort connection through a USB-C port, the listed maximum output
capacity is only available on external displays with a DisplayPort, a Mini DisplayPort, or a
USB-C port that supports DisplayPort Alternate Mode. For connections using a converter or
an adapter, the actual output resolution may be lower.
Security
• Fingerprint reader
• Nano security-lock slot
• UEFI/BIOS passwords
– Administrator password
– User password
– Master hard disk password
– User hard disk password
Network Bluetooth and Wi-Fi combo adapter
* for selected models
ThinkBook 16p G2 ACH
Dimensions
• Width: 354.6 mm (13.96 inches)
• Depth: 252 mm (9.92 inches)
• Thickness
– Thinnest: 15.9 mm (0.62 inches)
– Thickest: 19.9 mm (0.78 inches)
ac power adapter
• Input: 100 V ac–240 V ac, 50 Hz–60 Hz
• Output: 20 V dc, 11.5 A
• Power: 230 W
Battery pack
• Capacity: 70 Wh
• Number of cells: 4
Note: The battery capacity is the typical or average capacity as measured in a specific test
environment. Capacities measured in other environments may differ but are no lower than the
rated capacity (see product label).
Microprocessor To view the microprocessor information of your computer, type system information in the
Windows search box and then press Enter.
12 User Guide
