Lenovo B560 User Manual

32
Appendix A. CRU instructions
Replacing the hard disk drive - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
You can increase the storage capacity of your computer by replacing the hard disk drive with
one of greater capacity. You can purchase a new hard disk drive from your reseller or Lenovo
marketing representative.
The drive is very sensitive. Incorrect handling can cause damage and permanent loss of data on
the hard disk. Before removing the hard disk drive, make a backup copy of all the information
on the hard disk, and then turn the computer off. Never remove the drive while the system is
operating, in sleep mode, or in hibernation mode.
Notes:
• Replace the hard disk drive only if you upgrade it or have it repaired. The connectors and bay of the hard
disk drive were not designed for frequent changes, or drive swapping.
• The preinstalled softwares are not included on an optional hard disk drive.
Handling a hard disk drive
• Do not drop the drive or subject it to physical shocks. Put the drive on a material, such as
soft cloth, that absorbs the physical shock.
• Do not apply pressure to the cover of the drive.
• Do not touch the connector.

Lenovo B560 Specifications

General

Bus type	DMI
Stepping	K0
Tjunction	90 °C
Processor cache	3 MB
Processor cores	2
Processor model	P6100
System bus rate	2.5 GT/s
Processor family	Intel® Pentium®
Processor series	Intel Pentium P6000 Series for Mobile
Processor socket	PGA988
Processor codename	Arrandale
Processing Die size	81 mm²
Processor frequency	2 GHz
Processor cache type	Smart Cache
Processor lithography	32 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor operating modes	32-bit, 64-bit
ECC supported by processor	No
PCI Express configurations	1x16
Thermal Design Power (TDP)	35 W
CPU multiplier (bus/core ratio)	15
Maximum number of PCI Express lanes	1
Number of Processing Die Transistors	382 M
Motherboard chipset	-
HDD speed	5400 RPM
HDD interface	SATA
Optical drive type	DVD-RW
Card reader integrated	Yes
Total storage capacity	250 GB
Display diagonal	15.6 \
Display resolution	1366 x 768 pixels
Native aspect ratio	16:9
Type	PC
Power supply type	AC/DC
Power requirements	100-240V
Wireless technology	Wi-Fi
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Internal memory	2 GB
Internal memory type	DDR3-SDRAM
Maximum internal memory	- GB
On-board graphics card model	Intel® HD Graphics
On-board graphics card base frequency	500 MHz
On-board graphics card dynamic frequency (max)	667 MHz
Cabling technology	10/100/1000Base-T(X)
Networking features	Gigabit Ethernet
Operating system installed	Windows 7 Professional
Charging port type	DC-in jack
Serial ports quantity	0
USB 2.0 ports quantity	3
Product color	Black
Pointing device	Touchpad
Processor code	SLBUR
Processor ARK ID	50175
Processor package size	37.5x37.5 mm
Graphics & IMC lithography	45 nm
Physical Address Extension (PAE)	36 bit

Weight and Dimensions

Weight	2700 g
